Renesas ISL6843CBZ-T

Manufacturer No:

ISL6843CBZ-T

Manufacturer:

Renesas

Package:

SOIC

Description:

8 Terminals DC to DC converter IC SWITCHING CONTROLLER 1 Outputs 2MHz

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

ISL6843CBZ-T information

Renesas ISL6843CBZ-T technical specifications, attributes, parameters and parts with similar specifications to Renesas ISL6843CBZ-T.

Type
Parameter

Mount
Surface Mount

Package / Case
SOIC

Packaging
Tape & Reel

Published
2001

JESD-609 Code
e3

Part Status
Active

Moisture Sensitivity Level (MSL)
1 (Unlimited)

Number of Terminations
8

ECCN Code
EAR99

Terminal Finish
Matte Tin (Sn) - annealed

Max Operating Temperature
70°C

Min Operating Temperature
0°C

Technology
BICMOS

Terminal Position
DUAL

Terminal Form
GULL WING

Number of Functions
1

Pin Count
8

JESD-30 Code
R-PDSO-G8

Number of Outputs
1

Input Voltage-Nom
15V

Temperature Grade
COMMERCIAL

Analog IC - Other Type
SWITCHING CONTROLLER

Current - Output
1A

Frequency (Max)
2MHz

Control Mode
CURRENT-MODE

Frequency - Switching
2MHz

Control Technique
PULSE WIDTH MODULATION

Rise Time
20ns

Fall Time (Typ)
20 ns

Switcher Configuration
SINGLE

Duty Cycle (Max)
100 %

Length
4.9mm

Width
3.9mm

Radiation Hardening
No

RoHS Status
RoHS Compliant

Download datasheets and manufacturer documentation for Renesas ISL6843CBZ-T.

Datasheets:

intersil-isl6843cbzt-datasheets-5739.pdf

ISL6843CBZ-T Overview

Capsuled in the SOIC package, the switching controller suits most application needs. The dc motor controller is adquate to generate for 1 outputs. The pmic is packaged in Tape & Reel solid enclosure. This switching controller can switch at 2MHz. The switch converters are connected to a SWITCHING CONTROLLER analog IC. Terminal (s) of the switching converters are designed at the DUAL position. 8 terminations with a variety of function. To name a few of the control techniques these dc dc converter ics adapt, it includes PULSE WIDTH MODULATION. 15V nominal DC switcher's voltage input. The minimum input voltage of the dc dc voltage regulator should be 9V. DC switcher's Surface Mount makes it qualified for most application and prototype designs. DC switcher'sDC regulator should be kept at a temperature of 0°C or higher. DC regulator should run at a temperature of 70°C more than 70°C degrees Celsius. The switch converters have 1 function (s) in total. The dc switching comes with 8 pins set. The controller can switch at the maximum frequency of 2MHz. It is ideal for switching controllers with 1A input.
