Renesas ISL6504CBZ-T

Manufacturer No:

ISL6504CBZ-T

Manufacturer:

Renesas

Package:

SOIC

Description:

5V 1.27mm PMIC 5V SOIC

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

ISL6504CBZ-T information

Renesas ISL6504CBZ-T technical specifications, attributes, parameters and parts with similar specifications to Renesas ISL6504CBZ-T.

Type
Parameter

Mount
Surface Mount

Package / Case
SOIC

Published
2000

JESD-609 Code
e3

Part Status
Active

Moisture Sensitivity Level (MSL)
3 (168 Hours)

Number of Terminations
16

ECCN Code
EAR99

Terminal Finish
Matte Tin (Sn) - annealed

Max Operating Temperature
70°C

Min Operating Temperature
0°C

HTS Code
8542.39.00.01

Subcategory
Power Management Circuits

Terminal Position
DUAL

Terminal Form
GULL WING

Peak Reflow Temperature (Cel)
260

Number of Functions
1

Supply Voltage
5V

Terminal Pitch
1.27mm

Time@Peak Reflow Temperature-Max (s)
40

Pin Count
16

JESD-30 Code
R-PDSO-G16

Qualification Status
Not Qualified

Supply Voltage-Max (Vsup)
5.25V

Temperature Grade
COMMERCIAL

Supply Voltage-Min (Vsup)
4.75V

Number of Channels
4

Analog IC - Other Type
POWER SUPPLY SUPPORT CIRCUIT

Operating Supply Current
17mA

Adjustable Threshold
NO

Length
10.3mm

Height Seated (Max)
2.65mm

Width
7.5mm

RoHS Status
RoHS Compliant

Lead Free
Lead Free

Download datasheets and manufacturer documentation for Renesas ISL6504CBZ-T.

Datasheets:

intersil-isl6504cbzt-datasheets-1989.pdf

intersil-isl6504cbzt-datasheets-4376.pdf

ISL6504CBZ-T Overview

It is offered in the SOIC package in order to save space. An analog IC is used in this device, which is set to POWER SUPPLY SUPPORT CIRCUIT in this case. It has a total of 16 terminations. The peak of the reflow temperature is 260. It is equipped with a total of 16 pins. High efficiency is possible thanks to the 5V supply voltage. Currently, there are 4 channels accessible. This is a part of Power Management Circuits that has been included. The supply voltage (Vsup) should be kept above 4.75V for normal operation. Vsup (maximum supply voltage) is set to 5.25V. A supply current of 17mA is used to power this DC DC switching regulator. It is mounted according to the method of Surface Mount. It gets its energy from a 5V source. The operating temperature is indicated to be less than 70°C. The operating temperature should be more than 0°C.

ISL6504CBZ-T Features

SOIC package
Power Management Circuits subcategory
Minimum temperature of 0°C

ISL6504CBZ-T Applications

There are a lot of Intersil (Renesas Electronics America)
ISL6504CBZ-T Power Supply Control ICs applications.

Film engineering
Video conference system
Large conference system engineering
Screen lift
Monogram lift
Projector electric hanger lift
Multimedia classroom
Multi-purposed meeting room
Command and control center
Smart home
