Renesas ISL43L840IRZ
Renesas ISL43L840IRZ

Renesas ISL43L840IRZ

Manufacturer No:

ISL43L840IRZ

Manufacturer:

Renesas

Package:

QFN EP

Description:

QUAD Analog Switches BREAK-BEFORE-MAKE 2.7V QFN EP

Delivery:

DHL
DHL
DHL
DHL

Payment:

DHL
DHL
DHL
DHL
DHL
DHL
DHL

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

ISL43L840IRZ information

Renesas ISL43L840IRZ technical specifications, attributes, parameters and parts with similar specifications to Renesas ISL43L840IRZ.

  • Type
  • Parameter
  • Factory Lead Time
  • 6 Weeks
  • Mount
  • Surface Mount
  • Package / Case
  • QFN EP
  • Number of Pins
  • 16
  • Published
  • 2004
  • JESD-609 Code
  • e3
  • Part Status
  • Active
  • Moisture Sensitivity Level (MSL)
  • 2 (1 Year)
  • Number of Terminations
  • 16
  • Resistance
  • 750mOhm
  • Terminal Finish
  • Matte Tin (Sn) - annealed
  • Max Operating Temperature
  • 85°C
  • Min Operating Temperature
  • -40°C
  • Subcategory
  • Multiplexer or Switches
  • Technology
  • CMOS
  • Terminal Position
  • QUAD
  • Peak Reflow Temperature (Cel)
  • 260
  • Number of Functions
  • 1
  • Supply Voltage
  • 2.7V
  • Terminal Pitch
  • 0.5mm
  • Time@Peak Reflow Temperature-Max (s)
  • 30
  • Operating Supply Voltage
  • 3V
  • Temperature Grade
  • INDUSTRIAL
  • Number of Channels
  • 2
  • Min Supply Voltage
  • 1.6V
  • Analog IC - Other Type
  • DIFFERENTIAL MULTIPLEXER
  • Operating Supply Current
  • 50nA
  • Max Supply Current
  • 50nA
  • Propagation Delay
  • 33 ns
  • Logic Function
  • Demultiplexer, Multiplexer
  • Supply Type
  • Single
  • Off-state Isolation-Nom
  • 65 dB
  • On-state Resistance Match-Nom
  • 0.12Ohm
  • Switching
  • BREAK-BEFORE-MAKE
  • Height
  • 950?m
  • Length
  • 3mm
  • Width
  • 3mm
  • Radiation Hardening
  • No
  • RoHS Status
  • RoHS Compliant

Download datasheets and manufacturer documentation for Renesas ISL43L840IRZ.

Datasheets:

ISL43L840IRZ Overview


The electrical component comes in QFN EP packaging, which makes it convenient to ship overseas. In total, 16 terminations have occurred. A electrical component with 2 channels is capable of high-quality output. When the electronic component is given a voltage of 2.7V, it should be turned on and run. A 750mOhm internal resistance characterizes this multiplexer. The datasheets for the 16 pins explain the functions. The analog multiplexer shown here is a typical Multiplexer or Switches. An abnormal situation would be for the switch device to be supplied with a voltage greater than 3.6V. A analog switch ic that has a cost-effective Single supply type. It is recommended to use 1.6V as the lowest voltage for the electrical part. The analogue multiplexer could operate on 50nA current. A voltage higher than 50nA may cause damage to the switch multiplexer. Integrated with an analog IC DIFFERENTIAL MULTIPLEXER. This electrical part is compatible with 3V operating voltages. A temperature above 85°C is not suitable for operation of the analogue multiplexer.

ISL43L840IRZ Features


2 Channels
50nA Supply Current


ISL43L840IRZ Applications


There are a lot of Intersil (Renesas Electronics America)
ISL43L840IRZ Analog Switches & Multiplexers ICs applications.


  • Audio and video switching
  • Automatic test equipment
  • Precision data acquisition
  • Battery-powered systems
  • Sample-and-hold systems
  • Communication systems
  • Data Acquisition Systems
  • Relay Replacement
  • Battery Powered Systems
  • Existing multiplexer applications (both fault-protected and nonfault-protected)
