Renesas ISL43L740IR

Manufacturer No:

ISL43L740IR

Manufacturer:

Renesas

Package:

Description:

QUAD Analog Switches BREAK-BEFORE-MAKE 16 Pins 1.8V

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

ISL43L740IR information

Renesas ISL43L740IR technical specifications, attributes, parameters and parts with similar specifications to Renesas ISL43L740IR.

Type
Parameter

Mount
Surface Mount

Number of Pins
16

Packaging
Bulk

Published
2004

JESD-609 Code
e0

Moisture Sensitivity Level (MSL)
1 (Unlimited)

Number of Terminations
16

Resistance
750mOhm

Terminal Finish
Tin/Lead (Sn/Pb)

Max Operating Temperature
85°C

Min Operating Temperature
-40°C

HTS Code
8542.39.00.01

Subcategory
Multiplexer or Switches

Technology
CMOS

Terminal Position
QUAD

Terminal Form
NO LEAD

Peak Reflow Temperature (Cel)
NOT SPECIFIED

Number of Functions
1

Supply Voltage
1.8V

Terminal Pitch
0.5mm

Time@Peak Reflow Temperature-Max (s)
NOT SPECIFIED

Pin Count
16

Qualification Status
Not Qualified

Supply Voltage-Max (Vsup)
3.6V

Temperature Grade
INDUSTRIAL

Supply Voltage-Min (Vsup)
1.6V

Number of Channels
4

Analog IC - Other Type
DIFFERENTIAL MULTIPLEXER

Operating Supply Current
50nA

Throw Configuration
4PST

Logic Function
Demultiplexer, Multiplexer

Supply Type
Single

Supply Current-Max (Isup)
0.0009mA

On-state Resistance Match-Nom
0.12Ohm

Switching
BREAK-BEFORE-MAKE

Switch-on Time-Max
33ns

Switch-off Time-Max
25ns

Signal Current-Max
0.3A

Length
3mm

Height Seated (Max)
1mm

Width
3mm

RoHS Status
RoHS Compliant

Lead Free
Contains Lead

Download datasheets and manufacturer documentation for Renesas ISL43L740IR.

Datasheets:

intersil-isl43l740ir-datasheets-1925.pdf

ISL43L740IR Overview

This high-reliability packaging method uses advanced packaging methods Bulk. In total, there have been 16 terminations. A 4 channel electronic part produces high-quality output. A 1.8V voltage supply should turn on and run the electronic component. An injection of 16 pins is performed into the body of the electrical component. Analog switches have 750mOhm internal resistance. To find out what the 16 pins do, please refer to the datasheets. It is a typical Multiplexer or Switches analog multiplexer. Analog switch ics with Single supply type are cost-effective. It would be sufficient to run this analogue multiplexer with 50nA current. This product is integrated with an analog integrated circuit (IC) of type DIFFERENTIAL MULTIPLEXER. Temperatures higher than 85°C are not recommended for operation of the analogue multiplexer. Analog switch ics need a voltage of 1.6V to be powered.

ISL43L740IR Features

4 Channels
50nA Supply Current

ISL43L740IR Applications

There are a lot of Intersil (Renesas Electronics America)
ISL43L740IR Analog Switches & Multiplexers ICs applications.

Ultrasound
Audio and video switching
Automatic test equipment
Precision data acquisition
Battery-powered systems
Sample-and-hold systems
Communication systems
Data Acquisition Systems
Relay Replacement
Battery Powered Systems
