Renesas CS82C5496

Manufacturer No:

CS82C5496

Manufacturer:

Renesas

Package:

LCC

Description:

5V Programmable Timers 8MHz 5V LCC

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

CS82C5496 information

Renesas CS82C5496 technical specifications, attributes, parameters and parts with similar specifications to Renesas CS82C5496.

Type
Parameter

Contact Plating
Lead, Tin

Mount
Surface Mount

Package / Case
LCC

Number of Pins
28

Published
1996

JESD-609 Code
e0

Pbfree Code
no

Part Status
Active

Moisture Sensitivity Level (MSL)
1 (Unlimited)

Number of Terminations
28

ECCN Code
EAR99

Terminal Finish
Tin/Lead (Sn/Pb)

Max Operating Temperature
70°C

Min Operating Temperature
0°C

Technology
CMOS

Terminal Position
QUAD

Terminal Form
J BEND

Peak Reflow Temperature (Cel)
225

Supply Voltage
5V

Frequency
8MHz

Time@Peak Reflow Temperature-Max (s)
NOT SPECIFIED

Qualification Status
Not Qualified

Operating Supply Voltage
5V

Temperature Grade
COMMERCIAL

Min Supply Voltage
4.5V

Operating Supply Current
10mA

uPs/uCs/Peripheral ICs Type
TIMER, PROGRAMMABLE

Number of Bits
16

Propagation Delay
150 ns

Number of Timers/Counters
1

High Level Output Current
-2.5mA

External Data Bus Width
8

Low Level Output Current
2.5mA

Information Access Method
PARALLEL, DIRECT ADDRESS

Height Seated (Max)
4.57mm

RoHS Status
RoHS Compliant

Lead Free
Contains Lead

Download datasheets and manufacturer documentation for Renesas CS82C5496.

Datasheets:

intersil-cs82c5496-datasheets-7935.pdf

CS82C5496 Overview

In the packaging, the clock timer is enclosed with the LCC code on the back. The programmable timer is set to the frequency of 8MHz.To mount this digital timer with Surface Mount. The operating supply voltage is rated at 10mA voltage. The minimum operating temperature of the chip must not be lower than 0°C. It's best to use the timer clock when the temperature is below 70°C. The timer clock contains 28 pins. The digital timer's operating supply voltage is rated 5V voltage. The supply voltage of the programmable timer can rate 5V. The number of the chip's terminations sums up to 28. The minimum supply voltage of the chip must not be lower than 4.5V. The supply voltage of this chip should not exceed 5.5V. The number of Timers/Counters on the device is 1.

CS82C5496 Features

Operate frequency at 8MHz
Max Operating temperature at 0°C
1 Timers/Counters

CS82C5496 Applications

There are a lot of Intersil (Renesas Electronics America)
CS82C5496 Programmable Timers & Oscillators applications.

Remote Sensors
White Goods
Electric Vehicles
Always On Systems
Clutch Actuator circuit
Car Door Handle circuit
Smart Key
Remote current sensor
Intruder Detection
Power-On Reset Timer
