Renesas ISL12020MIRZ

Manufacturer No:

ISL12020MIRZ

Manufacturer:

Renesas

Package:

DFN

Description:

20 Terminations 3V 20 Pin Real Time Clocks 0.032MHz Min 2.7V V Max 5.5V V

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

ISL12020MIRZ information

Renesas ISL12020MIRZ technical specifications, attributes, parameters and parts with similar specifications to Renesas ISL12020MIRZ.

Type
Parameter

Factory Lead Time
7 Weeks

Contact Plating
Tin

Mount
Surface Mount

Package / Case
DFN

Number of Pins
20

Published
2008

JESD-609 Code
e3

Part Status
Active

Moisture Sensitivity Level (MSL)
1 (Unlimited)

Number of Terminations
20

ECCN Code
EAR99

Max Operating Temperature
85°C

Min Operating Temperature
-40°C

HTS Code
8542.39.00.01

Terminal Position
DUAL

Peak Reflow Temperature (Cel)
260

Supply Voltage
3V

Terminal Pitch
0.5mm

Pin Count
20

Power Supplies
3/5V

Temperature Grade
INDUSTRIAL

Interface
2-Wire, I2C, Serial

Max Supply Voltage
5.5V

Min Supply Voltage
2.7V

Clock Frequency
0.032MHz

Accuracy
0.0005 %

Logic Function
Clock

Time Format
HH:MM:SS

Non-Volatile Memory
128 B

Date Format
YY-MM-DD-dd

Time-Min
SECONDS

Interrupt Capability
Y

Information Access Method
I2C

Height
1.3mm

Length
5.5mm

Width
4mm

REACH SVHC
No SVHC

Radiation Hardening
No

RoHS Status
RoHS Compliant

Lead Free
Lead Free

Download datasheets and manufacturer documentation for Renesas ISL12020MIRZ.

Datasheets:

intersil-isl12020mirz-datasheets-1220.pdf

ISL12020MIRZ Overview

The package DFN contains real time clocks.It is possible to terminate a transmission line with a RTC module that matches the characteristic impedance of the line, which is known as 20 termination.Obviously, a voltage of 3V is being supplied to this electronic component.There are 20 pins on it.For storing data and programs, the RTC times embed a memory of 128B.Real time clocks' output frequency should not exceed 0.032MHz.Surface Mount is the mounting type of the RTC module.There are 3/5V power supplies attached to it.It is equipped with 20 pins.Ideally, the operating temperature should be higher than -40°C.Ideally, the operating temperature should be lower than 85°C.The minimal supply voltage is 2.7V.A maximum supply voltage of 5.5V is used.
