Manufacturer No:

IKW30N60H3FKSA1

Manufacturer:

INFINEON

Package:

TO-247-3

Description:

IGBT 600V 60A 187W TO247-3

Delivery:

DHL
DHL
DHL
DHL

Payment:

DHL
DHL
DHL
DHL
DHL
DHL

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

IKW30N60H3FKSA1 information

INFINEON IKW30N60H3FKSA1 technical specifications, attributes, parameters and parts with similar specifications to INFINEON IKW30N60H3FKSA1.

  • Type
  • Parameter
  • Factory Lead Time
  • 16 Weeks
  • Mount
  • Through Hole
  • Mounting Type
  • Through Hole
  • Package / Case
  • TO-247-3
  • Number of Pins
  • 3
  • Transistor Element Material
  • SILICON
  • Collector-Emitter Breakdown Voltage
  • 600V
  • Number of Elements
  • 1
  • Test Conditions
  • 400V, 30A, 10.5 Ω, 15V
  • Operating Temperature
  • -40°C~175°C TJ
  • Packaging
  • Tube
  • Series
  • TrenchStop®
  • Published
  • 2005
  • JESD-609 Code
  • e3
  • Pbfree Code
  • yes
  • Part Status
  • Active
  • Moisture Sensitivity Level (MSL)
  • 1 (Unlimited)
  • Number of Terminations
  • 3
  • ECCN Code
  • EAR99
  • Terminal Finish
  • Tin (Sn)
  • Max Power Dissipation
  • 187W
  • Peak Reflow Temperature (Cel)
  • NOT SPECIFIED
  • Time@Peak Reflow Temperature-Max (s)
  • NOT SPECIFIED
  • Base Part Number
  • *KW30N60
  • Qualification Status
  • Not Qualified
  • Element Configuration
  • Single
  • Input Type
  • Standard
  • Power - Max
  • 187W
  • Transistor Application
  • POWER CONTROL
  • Polarity/Channel Type
  • N-CHANNEL
  • Collector Emitter Voltage (VCEO)
  • 600V
  • Max Collector Current
  • 60A
  • Reverse Recovery Time
  • 38 ns
  • Turn On Time
  • 50 ns
  • Vce(on) (Max) @ Vge, Ic
  • 2.4V @ 15V, 30A
  • Turn Off Time-Nom (toff)
  • 262 ns
  • IGBT Type
  • Trench Field Stop
  • Gate Charge
  • 165nC
  • Current - Collector Pulsed (Icm)
  • 120A
  • Td (on/off) @ 25°C
  • 21ns/207ns
  • Switching Energy
  • 1.38mJ
  • RoHS Status
  • ROHS3 Compliant
  • Lead Free
  • Lead Free

Download datasheets and manufacturer documentation for INFINEON IKW30N60H3FKSA1.

Datasheets:

Other Related Documents:

PCN Design/Specification:

ConflictMineralStatement:

IKW30N60H3FKSA1 Description


The IKW30N60H3FKSA1 is a High-speed DuoPack: IGBT in Trench and Fieldstop technology with soft, fast recovery anti-parallel diode. The BJT and MOSFET are combined to form the IGBT or Insulated Gate Bipolar Transistor. Its name also alluded to their union. The term "Insulated Gate" describes a MOSFET's extremely high input impedance. It relies on the voltage at its gate terminal to operate rather than drawing any input current. When a BJT's output portion is described as "bipolar," it means that both different types of charge carriers contribute to the current flow. It enables it to operate with extremely high currents and voltages while utilizing low voltage signals. The IGBT is a voltage-controlled device as a result of this hybrid arrangement.



IKW30N60H3FKSA1 Features


  • Maximum junction temperature 175°C

  • Qualified according to JEDEC for target applications

  • Pb-free lead plating; RoHS compliant

  • Very low VCEsat

  • Low EMI

  • Very soft, fast recovery anti-parallel diode



IKW30N60H3FKSA1 Applications


  • Uninterruptible power supplies

  • Welding converters

  • Converters with high switching frequency

  • Switched Mode Power Supply

  • AC and DC motor drives
