Renesas HIP6004BCBZA-T

Manufacturer No:

HIP6004BCBZA-T

Manufacturer:

Renesas

Package:

SOIC

Description:

3.5V 260 Cel DUAL Specialized Voltage Regulator 20, 20 Pins 20 Terminations SOIC

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

HIP6004BCBZA-T information

Renesas HIP6004BCBZA-T technical specifications, attributes, parameters and parts with similar specifications to Renesas HIP6004BCBZA-T.

Type
Parameter

Mount
Surface Mount

Package / Case
SOIC

Published
1999

JESD-609 Code
e3

Part Status
Active

Moisture Sensitivity Level (MSL)
3 (168 Hours)

Number of Terminations
20

ECCN Code
EAR99

Terminal Finish
Matte Tin (Sn) - annealed

Max Operating Temperature
70°C

Min Operating Temperature
0°C

Terminal Position
DUAL

Terminal Form
GULL WING

Peak Reflow Temperature (Cel)
260

Number of Functions
1

Time@Peak Reflow Temperature-Max (s)
40

Pin Count
20, 20

JESD-30 Code
R-PDSO-G20

Number of Outputs
1

Qualification Status
Not Qualified

Operating Supply Voltage
12V

Input Voltage-Nom
12V

Temperature Grade
COMMERCIAL

Analog IC - Other Type
SWITCHING CONTROLLER

Voltage - Output
3.5V

Control Mode
VOLTAGE-MODE

Frequency - Switching
1MHz

Control Technique
PULSE WIDTH MODULATION

Switcher Configuration
PUSH-PULL

Max Duty Cycle
100 %

Height Seated (Max)
2.65mm

Width
7.5mm

RoHS Status
RoHS Compliant

Lead Free
Lead Free

Download datasheets and manufacturer documentation for Renesas HIP6004BCBZA-T.

Datasheets:

intersil-hip6004bcbzat-datasheets-0459.pdf

HIP6004BCBZA-T Overview

There are 1 outputs supported by the voltage regulator. Transport is made easy with the package of SOIC. Volatge output for this voltage controller is 3.5V. It contains terminals with the number 20. The part has received praise for being a SWITCHING CONTROLLER voltage regulator. Initially, the pinout of the alternator regulator begins with 20, 20 pins. Surface Mount is there for mounting on a PCB or another board. It cannot be operated at temperatures below 0°C. In general, temperatures higher than 70°Care not recommended. It is necessary to have an operating supply voltage of 12V for normal operation. In this voltage regulator, the switching frequency is set to 1MHz.

HIP6004BCBZA-T Features

SWITCHING CONTROLLER analog IC
Supply voltage: 12V
Switching at 1MHz

HIP6004BCBZA-T Applications

There are a lot of Intersil (Renesas Electronics America)
HIP6004BCBZA-T Specialized Voltage Regulators applications.

DDR Vooo and V? Voltage Generation
PC Dual Power Supply
Server DDR Power
Desktop Computer
Graphics Cards
Cell Phones
Wireless Modems
PCS Phones
Two-Way Pagers
PHS Phones
