HIROSE FH19SC-20S-0.5SH(99)
HIROSE FH19SC-20S-0.5SH(99)

HIROSE FH19SC-20S-0.5SH(99)

Manufacturer No:

FH19SC-20S-0.5SH(99)

Manufacturer:

HIROSE

Package:

Description:

FH19SC Series FFC, FPC Contacts, Bottom Tape & Reel (TR) 0.020 0.50mm Solder 20 Positions Surface Mount, Right Angle Gold -55°C~85°C 0.5A

Delivery:

DHL
DHL
DHL
DHL

Payment:

DHL
DHL
DHL
DHL
DHL
DHL

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

FH19SC-20S-0.5SH(99) information

HIROSE FH19SC-20S-0.5SH(99) technical specifications, attributes, parameters and parts with similar specifications to HIROSE FH19SC-20S-0.5SH(99).

  • Type
  • Parameter
  • Factory Lead Time
  • 10 Weeks
  • Contact Material
  • Phosphor Bronze
  • Mount
  • Surface Mount
  • Mounting Type
  • Surface Mount, Right Angle
  • Housing Material
  • Liquid Crystal Polymer (LCP), Halogen Free
  • Actuator Material
  • Liquid Crystal Polymer (LCP), Polyphenylene Sulfide (PPS)
  • Operating Temperature
  • -55°C~85°C
  • Packaging
  • Tape & Reel (TR)
  • Series
  • FH19SC
  • Feature
  • Solder Retention, Zero Insertion Force (ZIF)
  • Part Status
  • Active
  • Moisture Sensitivity Level (MSL)
  • 1 (Unlimited)
  • Termination
  • Solder
  • ECCN Code
  • EAR99
  • Connector Type
  • FFC/FPC CONNECTOR
  • Number of Positions
  • 20
  • Number of Rows
  • 1
  • Gender
  • Receptacle
  • Voltage - Rated
  • 50V
  • HTS Code
  • 8536.69.40.40
  • Subcategory
  • Headers and Edge Type Connectors
  • Current Rating (Amps)
  • 0.5A
  • Pitch
  • 0.020 0.50mm
  • Total Number of Contacts
  • 20
  • Current Rating
  • 500mA
  • Reference Standard
  • UL
  • Contact Finish
  • Gold
  • Reliability
  • COMMERCIAL
  • Body Length or Diameter
  • 0.472 inch
  • Number Of PCB Rows
  • 1
  • PCB Contact Pattern
  • RECTANGULAR
  • Body Breadth
  • 0.004 inch
  • Housing Color
  • Beige
  • Body Depth
  • 0.138 inch
  • Contact Style
  • BELLOWED TYPE
  • Contact Resistance
  • 100mOhm
  • Insulation Resistance
  • 500000000Ohm
  • Contact Pattern
  • RECTANGULAR
  • Flat Flex Type
  • FFC, FPC
  • Connector/Contact Type
  • Contacts, Bottom
  • Cable End Type
  • Tapered
  • Locking Feature
  • Flip Lock
  • Actuator Color
  • Black
  • Height Above Board
  • 0.037 0.95mm
  • FFC, FCB Thickness
  • 0.30mm
  • Material Flammability Rating
  • UL94 V-0
  • RoHS Status
  • RoHS Compliant

Download datasheets and manufacturer documentation for HIROSE FH19SC-20S-0.5SH(99).

Datasheets:

FH19SC-20S-0.5SH(99) Overview


Packaging is FFC/FPC CONNECTOR.This device has a Surface Mount, Right Angle mounting type.An orange Tape & Reel (TR) case is used to package the product.Specifically, it is one of the products in the FH19SC Series.Several benefits come from the Solder Retention, Zero Insertion Force (ZIF) feature.There is a mounting hole at Surface Mount.Devices operate at -55°C~85°C operating temperatures.
