Manufacturer No:

FH12S-50S-0.5SH(55)

Manufacturer:

HIROSE

Package:

Description:

FH12 Series FFC, FPC Contacts, Bottom Tape & Reel (TR) 0.020 0.50mm Solder 50 Positions Surface Mount, Right Angle Gold -40°C~85°C 0.5A

Delivery:

DHL
DHL
DHL
DHL

Payment:

DHL
DHL
DHL
DHL
DHL
DHL

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

FH12S-50S-0.5SH(55) information

HIROSE FH12S-50S-0.5SH(55) technical specifications, attributes, parameters and parts with similar specifications to HIROSE FH12S-50S-0.5SH(55).

  • Type
  • Parameter
  • Factory Lead Time
  • 10 Weeks
  • Contact Material
  • Phosphor Bronze
  • Mount
  • Surface Mount
  • Mounting Type
  • Surface Mount, Right Angle
  • Material
  • Polyamide
  • Housing Material
  • Polyamide (PA), Nylon
  • Actuator Material
  • Polyphenylene Sulfide (PPS)
  • Operating Temperature
  • -40°C~85°C
  • Packaging
  • Tape & Reel (TR)
  • Series
  • FH12
  • JESD-609 Code
  • e4
  • Feature
  • Zero Insertion Force (ZIF)
  • Pbfree Code
  • yes
  • Part Status
  • Active
  • Moisture Sensitivity Level (MSL)
  • 1 (Unlimited)
  • Termination
  • Solder
  • Connector Type
  • FFC/FPC CONNECTOR
  • Number of Positions
  • 50
  • Color
  • Beige, Brown
  • Number of Rows
  • 1
  • Gender
  • Receptacle
  • Subcategory
  • Headers and Edge Type Connectors
  • MIL Conformance
  • NO
  • DIN Conformance
  • NO
  • Filter Feature
  • NO
  • Mixed Contacts
  • NO
  • Option
  • GENERAL PURPOSE
  • Current Rating (Amps)
  • 0.5A
  • Pitch
  • 0.020 0.50mm
  • Total Number of Contacts
  • 50
  • Orientation
  • Right Angle
  • Depth
  • 5.6mm
  • Current Rating
  • 500mA
  • Reference Standard
  • UL
  • Contact Finish
  • Gold
  • Voltage - Rated AC
  • 50V
  • Reliability
  • COMMERCIAL
  • Number Of PCB Rows
  • 1
  • Lead Pitch
  • 500?m
  • PCB Contact Pattern
  • RECTANGULAR
  • Body Breadth
  • 0.079 inch
  • UL Flammability Code
  • 94V-0
  • Housing Color
  • Beige
  • Contact Style
  • BELLOWED TYPE
  • Contact Resistance
  • 50mOhm
  • Insulation Resistance
  • 500MOhm
  • Max Voltage Rating (AC)
  • 50V

Download datasheets and manufacturer documentation for HIROSE FH12S-50S-0.5SH(55).

Datasheets:

FH12S-50S-0.5SH(55) Overview


The connector type FFC/FPC CONNECTOR refers to the connector type.The device's mounting type is Surface Mount, Right Angle.In order to package the product, a Tape & Reel (TR) case is used.It belongs to the FH12 Series of products.Its Zero Insertion Force (ZIF) feature renders it more powerful in many ways.The part is mounted by Surface Mount.The device runs in -40°C~85°C Operating Temperature.
