Manufacturer No:

FH12-24S-0.5SVA(54)

Manufacturer:

HIROSE

Package:

Description:

FH12 Series FFC, FPC Contacts, Vertical - 1 Sided Tape & Reel (TR) 0.020 0.50mm Solder 24 Positions Surface Mount Gold -40°C~85°C 0.5A

Delivery:

DHL
DHL
DHL
DHL

Payment:

DHL
DHL
DHL
DHL
DHL
DHL

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

FH12-24S-0.5SVA(54) information

HIROSE FH12-24S-0.5SVA(54) technical specifications, attributes, parameters and parts with similar specifications to HIROSE FH12-24S-0.5SVA(54).

  • Type
  • Parameter
  • Factory Lead Time
  • 10 Weeks
  • Contact Material
  • Phosphor Bronze
  • Mount
  • Surface Mount
  • Mounting Type
  • Surface Mount
  • Material
  • Polyamide
  • Housing Material
  • Polyamide (PA), Nylon
  • Actuator Material
  • Polyphenylene Sulfide (PPS)
  • Operating Temperature
  • -40°C~85°C
  • Packaging
  • Tape & Reel (TR)
  • Series
  • FH12
  • Feature
  • Solder Retention, Zero Insertion Force (ZIF)
  • Part Status
  • Active
  • Moisture Sensitivity Level (MSL)
  • 1 (Unlimited)
  • Termination
  • Solder
  • ECCN Code
  • EAR99
  • Connector Type
  • FFC/FPC CONNECTOR
  • Number of Positions
  • 24
  • Number of Rows
  • 1
  • Gender
  • Receptacle
  • Filter Feature
  • NO
  • Mixed Contacts
  • NO
  • Option
  • GENERAL PURPOSE
  • Current Rating (Amps)
  • 0.5A
  • Pitch
  • 0.020 0.50mm
  • Current Rating
  • 500mA
  • Number of Conductors
  • ONE
  • Reference Standard
  • UL
  • Contact Finish
  • Gold
  • Voltage - Rated AC
  • 50V
  • Number Of PCB Rows
  • 2
  • PCB Contact Pattern
  • STAGGERED
  • UL Flammability Code
  • 94V-0
  • Contact Style
  • BELLOWED TYPE
  • Contact Resistance
  • 50mOhm
  • Insulation Resistance
  • 500MOhm
  • Contact Pattern
  • RECTANGULAR
  • Flat Flex Type
  • FFC, FPC
  • Connector/Contact Type
  • Contacts, Vertical - 1 Sided
  • Cable End Type
  • Straight
  • Locking Feature
  • Flip Lock
  • Width
  • 15.4mm
  • Height Above Board
  • 0.142 3.60mm
  • FFC, FCB Thickness
  • 0.30mm
  • Material Flammability Rating
  • UL94 V-0
  • REACH SVHC
  • Unknown
  • RoHS Status
  • RoHS Compliant
  • Flammability Rating
  • UL94 V-0

Download datasheets and manufacturer documentation for HIROSE FH12-24S-0.5SVA(54).

Datasheets:

FH12-24S-0.5SVA(54) Overview


Packaging for this item is FFC/FPC CONNECTOR.Surface Mount is the type of mounting for the device.To package the product, a Tape & Reel (TR) case is used.The product is a member of the FH12 Series.It is more powerful in many ways due to its Solder Retention, Zero Insertion Force (ZIF) feature.It is mounted by Surface Mount.It operates at an operating temperature of -40°C~85°C.
