ONSEMI FAN6100MMPX

Manufacturer No:

FAN6100MMPX

Manufacturer:

ONSEMI

Package:

20-WFQFN Exposed Pad

Description:

Adjustable PMIC 20 Pin 20-WFQFN Exposed Pad

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

FAN6100MMPX information

ONSEMI FAN6100MMPX technical specifications, attributes, parameters and parts with similar specifications to ONSEMI FAN6100MMPX.

Type
Parameter

Lifecycle Status
LAST SHIPMENTS (Last Updated: 1 week ago)

Factory Lead Time
6 Weeks

Mount
Surface Mount

Mounting Type
Surface Mount

Package / Case
20-WFQFN Exposed Pad

Number of Pins
20

Weight
170.66666mg

Operating Temperature
-40°C~125°C

Packaging
Tape & Reel (TR)

Published
2016

JESD-609 Code
e4

Pbfree Code
yes

Part Status
Obsolete

Moisture Sensitivity Level (MSL)
1 (Unlimited)

ECCN Code
EAR99

Terminal Finish
Nickel/Palladium/Gold/Silver (Ni/Pd/Au/Ag)

Applications
Secondary-Side Controller

Voltage - Supply
3.12V~6V

Peak Reflow Temperature (Cel)
260

Time@Peak Reflow Temperature-Max (s)
NOT SPECIFIED

Number of Outputs
1

Output Type
Adjustable

Operating Supply Voltage
6V

Analog IC - Other Type
SWITCHING CONTROLLER

Voltage - Input
Up to 16V

Topology
Boost

Max Input Voltage
6V

Isolation
Isolated

Switching Frequency
125kHz

RoHS Status
RoHS Compliant

Download datasheets and manufacturer documentation for ONSEMI FAN6100MMPX.

FAN6100MMPX Overview

In Tape & Reel (TR), it is packaged. As a space-saving measure, it is included in the 20-WFQFN Exposed Pad package. The mounting is done according to Surface Mount. In order for the system to function properly, the temperature must be kept at -40°C~125°C. The device is an outstanding choice for Secondary-Side Controller owing to its outstanding performance. As a result of the 3.12V~6V supply voltage, high efficiency is possible. In this device, the analog IC SWITCHING CONTROLLER is used. In the reflow process, the peak temperature is 260. The design uses 20 pins. Power for this DC DC switching regulator is provided by a supply current of 2.4mA. Using the Surface Mount method, it is mounted. Input voltage Up to 16V is provided. This device is equipped with 1 outputs.

FAN6100MMPX Features

20-WFQFN Exposed Pad package
Mounting type of Surface Mount

FAN6100MMPX Applications

There are a lot of ON Semiconductor
FAN6100MMPX Power Supply Control ICs applications.

Monogram lift
Projector electric hanger lift
Multimedia classroom
Multi-purposed meeting room
Command and control center
Smart home
User-available push-button control panel
Computer monitor
Touch screen
Remote control
