Renesas EL5624IREZ-T13

Manufacturer No:

EL5624IREZ-T13

Manufacturer:

Renesas

Package:

HTSSOP EP

Description:

6 Channels 140mA per Channel 50nA 45 dB Instrumentational OP Amps 0.05μA 8.25V 20 Pins HTSSOP EP

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

EL5624IREZ-T13 information

Renesas EL5624IREZ-T13 technical specifications, attributes, parameters and parts with similar specifications to Renesas EL5624IREZ-T13.

Type
Parameter

Mount
Surface Mount

Package / Case
HTSSOP EP

Published
2003

JESD-609 Code
e3

Moisture Sensitivity Level (MSL)
3 (168 Hours)

Number of Terminations
20

ECCN Code
EAR99

Terminal Finish
MATTE TIN

Max Operating Temperature
85°C

Min Operating Temperature
-40°C

HTS Code
8542.33.00.01

Subcategory
Buffer Amplifier

Technology
CMOS

Terminal Position
DUAL

Terminal Form
GULL WING

Peak Reflow Temperature (Cel)
260

Number of Functions
6

Supply Voltage
15V

Time@Peak Reflow Temperature-Max (s)
40

Pin Count
20

JESD-30 Code
R-PDSO-G20

Qualification Status
Not Qualified

Operating Supply Voltage
8.25V

Temperature Grade
INDUSTRIAL

Operating Supply Current
6.8mA

Nominal Supply Current
8.5mA

Current - Output
30mA

Slew Rate
15 V/μs

Amplifier Type
BUFFER

Common Mode Rejection Ratio
45 dB

Current - Input Bias
50nA

Output Current per Channel
140mA

Input Offset Voltage (Vos)
14mV

Gain Bandwidth Product
8MHz

Voltage Gain
0.069dB

Average Bias Current-Max (IIB)
0.05μA

-3db Bandwidth
12MHz

Min Dual Supply Voltage
2.25V

Height Seated (Max)
1.2mm

RoHS Status
RoHS Compliant

Lead Free
Lead Free

Download datasheets and manufacturer documentation for Renesas EL5624IREZ-T13.

EL5624IREZ-T13 Overview

The linear amplifier is packaged in a HTSSOP EP case. This is a BUFFER type op amp. The number of terminations approaches 20. Buffer amplifier has a total of 20 pins. Please take in mind that this instrumentation amplifier should be run at 15V. To be specific, this instrumentation amplifier is a type of Buffer Amplifier. Regarding input offset voltage, op amp rates 14mV. This op amp can operate from a supply current at 6.8mA. Voltage gain should remain at 0.069dB. The op amp ic has 6 channels on it. The temperature should not be lower than -40°C for operational amplifier ics to operate. Use op amps only at temperatures no higher than 85°C. The operating supply voltage of the buffer op amp is rated at 8.25V.
