Panasonic EEH-ZA1V220R
Panasonic EEH-ZA1V220R

Panasonic EEH-ZA1V220R

Manufacturer No:

EEH-ZA1V220R

Manufacturer:

Panasonic

Package:

Radial, Can - SMD

Description:

22μF ±20% Radial, Can - SMD 0.240 6.10mm Tape & Reel (TR) 100mOhm ZA Surface Mount Hybrid Automotive

Delivery:

DHL
DHL
DHL
DHL

Payment:

DHL
DHL
DHL
DHL
DHL
DHL

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

EEH-ZA1V220R information

Panasonic EEH-ZA1V220R technical specifications, attributes, parameters and parts with similar specifications to Panasonic EEH-ZA1V220R.

  • Type
  • Parameter
  • Factory Lead Time
  • 12 Weeks
  • Mount
  • PCB, Surface Mount
  • Mounting Type
  • Surface Mount
  • Package / Case
  • Radial, Can - SMD
  • Terminal Shape
  • FLAT
  • Material
  • Polymer
  • Surface Mount Land Size
  • 0.209Lx0.209W 5.30mmx5.30mm
  • Lifetime @ Temp.
  • 10000 Hrs @ 105°C
  • Operating Temperature
  • -55°C~105°C
  • Packaging
  • Tape & Reel (TR)
  • Series
  • ZA
  • Published
  • 2012
  • Size / Dimension
  • 0.197Dia 5.00mm
  • Tolerance
  • ±20%
  • Part Status
  • Active
  • Moisture Sensitivity Level (MSL)
  • 1 (Unlimited)
  • Number of Terminations
  • 2
  • Termination
  • SMD/SMT
  • ECCN Code
  • EAR99
  • Type
  • Hybrid
  • Applications
  • Automotive
  • HTS Code
  • 8532.24.0020
  • Capacitance
  • 22μF
  • Voltage - Rated DC
  • 35V
  • Lead Pitch
  • 1.5mm
  • ESR (Equivalent Series Resistance)
  • 100mOhm
  • Polarity
  • Polar
  • Lead Diameter
  • 650 μm
  • Size Code
  • 2121
  • Voltage
  • 35V
  • Leakage Current
  • 7.7μA
  • Ripple Current
  • 900mA
  • Life (Hours)
  • 5000 hours
  • Tan Delta
  • .12
  • Ripple Current @ Low Frequency
  • 90mA @ 100Hz
  • Ripple Current @ High Frequency
  • 900mA @ 100kHz
  • Ripple Current (AC)
  • 900mA
  • Diameter
  • 5mm
  • Height
  • 5.8mm
  • Height Seated (Max)
  • 0.240 6.10mm
  • REACH SVHC
  • No SVHC
  • Radiation Hardening
  • No
  • RoHS Status
  • RoHS Compliant
  • Lead Free
  • Lead Free
  • Ratings
  • AEC-Q200

Download datasheets and manufacturer documentation for Panasonic EEH-ZA1V220R.

Datasheets:

Environmental Information:

EEH-ZA1V220R Overview


Systems need 900mA @ 100kHz ripple current at high frequencies in order to function.A value of 100mOhm is assigned to the electrical device's ESR (Equivalent Series Resistance).Providing a ripple current at low frequency is necessary for 90mA @ 100Hz to function properly.A stable operation requires an operating temperature of -55°C~105°C.

EEH-ZA1V220R Features


900mA @ 100kHz ripple current on a high frequency
a 100mOhm in ESR (Equivalent Series Resistance) in this electrical device
an operating temperature of -55°C~105°C


EEH-ZA1V220R Applications


There are a lot of Panasonic Electronic Components
EEH-ZA1V220R applications of aluminum polymer capacitors.


  • LED driver power supplies
  • Phone chargers
  • Motherboards
  • Servers and adapters (laptop power supplies)
  • Medical equipment
  • Switching Power Supply and DC/DC Converter.
  • Buck up Power Supplies of CPU(VRM etc.)
  • Miniature high Power Supply.
