DIODES DMN32D2LFB4-7
DIODES DMN32D2LFB4-7

DIODES DMN32D2LFB4-7

Manufacturer No:

DMN32D2LFB4-7

Manufacturer:

DIODES

Package:

3-XFDFN

Description:

MOSFET (Metal Oxide) N-Channel Tape & Reel (TR) 1.2 ? @ 100mA, 4V ±10V 39pF @ 3V 3-XFDFN

Delivery:

DHL
DHL
DHL
DHL

Payment:

DHL
DHL
DHL
DHL
DHL
DHL

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

DMN32D2LFB4-7 information

DIODES DMN32D2LFB4-7 technical specifications, attributes, parameters and parts with similar specifications to DIODES DMN32D2LFB4-7.

  • Type
  • Parameter
  • Factory Lead Time
  • 15 Weeks
  • Contact Plating
  • Gold
  • Mount
  • Surface Mount
  • Mounting Type
  • Surface Mount
  • Package / Case
  • 3-XFDFN
  • Number of Pins
  • 3
  • Transistor Element Material
  • SILICON
  • Operating Temperature
  • -55°C~150°C TJ
  • Packaging
  • Tape & Reel (TR)
  • Published
  • 2017
  • JESD-609 Code
  • e4
  • Pbfree Code
  • yes
  • Part Status
  • Active
  • Moisture Sensitivity Level (MSL)
  • 1 (Unlimited)
  • Number of Terminations
  • 3
  • ECCN Code
  • EAR99
  • Resistance
  • 1.2Ohm
  • Additional Feature
  • HIGH RELIABILITY
  • Subcategory
  • FET General Purpose Powers
  • Technology
  • MOSFET (Metal Oxide)
  • Terminal Position
  • BOTTOM
  • Peak Reflow Temperature (Cel)
  • 260
  • Time@Peak Reflow Temperature-Max (s)
  • 40
  • Pin Count
  • 3
  • Number of Channels
  • 1
  • Power Dissipation-Max
  • 350mW Ta
  • Element Configuration
  • Single
  • Operating Mode
  • ENHANCEMENT MODE
  • Power Dissipation
  • 350mW
  • Case Connection
  • DRAIN
  • Turn On Delay Time
  • 11 ns
  • FET Type
  • N-Channel
  • Transistor Application
  • SWITCHING
  • Rds On (Max) @ Id, Vgs
  • 1.2 ? @ 100mA, 4V
  • Vgs(th) (Max) @ Id
  • 1.2V @ 250?A
  • Input Capacitance (Ciss) (Max) @ Vds
  • 39pF @ 3V
  • Current - Continuous Drain (Id) @ 25°C
  • 300mA Ta
  • Drive Voltage (Max Rds On,Min Rds On)
  • 1.8V 4V
  • Vgs (Max)
  • ±10V
  • Turn-Off Delay Time
  • 51 ns
  • Continuous Drain Current (ID)
  • 300mA
  • Gate to Source Voltage (Vgs)
  • 10V
  • Drain to Source Breakdown Voltage
  • 30V
  • Height
  • 350?m
  • Length
  • 1mm
  • Width
  • 600?m
  • REACH SVHC
  • No SVHC

DMN32D2LFB4-7 Overview


The input capacitance parameter, CI, is defined as the capacitance between the input terminals of an op amp with either input grounded, and this device's maximal input capacitance is 39pF @ 3V.The drain current is the maximum continuous current the device can conduct, and the continuous drain current (ID) of this device is 300mA. Drain-source breakdown voltage is the VDS at which a specified value of ID flows, with VGS=30V. And this device has 30V drain to source breakdown voltage.Turn-Off delay time is the time taken to charge the input capacitance of the device before drain current conduction can start, and its turn-off delay time is 51 ns.Turn-on delay time is the time taken to charge the input capacitance of the device before drain current conduction can start, and its delay time is 11 ns.The gate-source voltage, VGS, of a FET transistor is the voltage that falls across the gate-source terminal of the transistor and its voltage can be 10V.By using drive voltage (1.8V 4V), this device helps reduce its overall power consumption.

DMN32D2LFB4-7 Features


a continuous drain current (ID) of 300mA
a drain-to-source breakdown voltage of 30V voltage
the turn-off delay time is 51 ns


DMN32D2LFB4-7 Applications


There are a lot of Diodes Incorporated
DMN32D2LFB4-7 applications of single MOSFETs transistors.


  • LCD/LED TV
  • Consumer Appliances
  • Lighting
  • Uninterruptible Power Supply
  • AC-DC Power Supply
  • Synchronous Rectification for ATX 1 Server I Telecom PSU
  • Motor drives and Uninterruptible Power Supplies
  • Micro Solar Inverter
  • DC/DC converters
  • Power Tools
