Microchip CL520K4-G

Manufacturer No:

CL520K4-G

Manufacturer:

Microchip

Package:

TO-252-3, DPak (2 Leads + Tab), SC-63

Description:

LINEAR, FIXED CONSTANT CURRENT LED DRIVER

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

CL520K4-G information

Microchip CL520K4-G technical specifications, attributes, parameters and parts with similar specifications to Microchip CL520K4-G.

Type
Parameter

+Vin min (V)
4.75

+Vin max (V)
90

Vout min (V)
1.0

Vout max (V)
90

Output Current (mA)
20

Dimming
No

Parallelable
Yes

Package
TO-252, TO-92

Features
--

Download datasheets and manufacturer documentation for Microchip CL520K4-G.

Data Sheets:

c23f90d79032f60837a058f268200ecd.pdf

The CL520 is a fixed, linear current regulator designed for driving LEDs at 20mA. With a maximum rating of 90V, it is able to withstand transients without the need for additional transient protection circuitry. It is ideally suited for applications employing single or multiple LEDs. The minimum dropout voltage of 1.0V accomodates extra LEDs, permits lower supply voltages, and provides more efficient operation. The CL520 is offered in TO-252(D-PAK) and TO-92 packages.

20mA ±10% constant current drive
1.0V dropout
90V rating for transient immunity
Temperature compensated
4.75 - 90V supply range
