Comchip Technology CDBB340-G

Manufacturer No:

CDBB340-G

Manufacturer:

Comchip Technology

Package:

DO-214AA, SMB

Description:

Schottky Diode Rectifier Fast Recovery =< 500ns, > 200mA (Io) 500mV @ 3A 125°C Max 500?A @ 40V Tape & Reel (TR) DO-214AA, SMB Surface Mount

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

CDBB340-G information

Comchip Technology CDBB340-G technical specifications, attributes, parameters and parts with similar specifications to Comchip Technology CDBB340-G.

Type
Parameter

Mount
Surface Mount

Mounting Type
Surface Mount

Package / Case
DO-214AA, SMB

Packaging
Tape & Reel (TR)

Published
2011

Part Status
Not For New Designs

Moisture Sensitivity Level (MSL)
1 (Unlimited)

ECCN Code
EAR99

HTS Code
8541.10.00.80

Subcategory
Rectifier Diodes

Base Part Number
CDBB340

Operating Temperature (Max)
150°C

Number of Elements
1

Configuration
SINGLE

Speed
Fast Recovery =< 500ns, > 200mA (Io)

Diode Type
Schottky

Current - Reverse Leakage @ Vr
500?A @ 40V

Voltage - Forward (Vf) (Max) @ If
500mV @ 3A

Max Reverse Leakage Current
500?A

Operating Temperature - Junction
125°C Max

Max Surge Current
80A

Output Current-Max
3A

Max Reverse Voltage (DC)
40V

Average Rectified Current
3A

Download datasheets and manufacturer documentation for Comchip Technology CDBB340-G.

Datasheets:

comchiptechnology-cdbb3100hf-datasheets-0239.pdf

CDBB340-G Overview

A maximum reverse leakage current of 500?A volts is produced by this device.This device has an average rectified current of 3A volts.Surge currents can be used up to 80A.The maximum output current is 3A.

CDBB340-G Features

a maximal reverse leakage current of 500?A volts
an average rectified current of 3A volts
3A is the maximum value

CDBB340-G Applications

There are a lot of Comchip Technology
CDBB340-G applications of single-phase diode rectifier.

DC motor control and drives
Battery chargers
Welders
Power converters
Reverse Polarity Protection
Ultra High-Speed Switching
Freewheeling
Polarity Protection Diode
Recirculating Diode
Switching Diode
