ADI ADSP-BF538BBCZ-5A

Manufacturer No:

ADSP-BF538BBCZ-5A

Manufacturer:

ADI

Package:

316-LFBGA, CSPBGA

Description:

0.8mm 148kB CPLD Blackfin® Series ADSP-BF538 316 Pin 533MHz 1.2V 316-LFBGA, CSPBGA

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

ADSP-BF538BBCZ-5A information

ADI ADSP-BF538BBCZ-5A technical specifications, attributes, parameters and parts with similar specifications to ADI ADSP-BF538BBCZ-5A.

Type
Parameter

Lifecycle Status
PRODUCTION (Last Updated: 1 month ago)

Factory Lead Time
10 Weeks

Mount
Surface Mount

Mounting Type
Surface Mount

Package / Case
316-LFBGA, CSPBGA

Number of Pins
316

Operating Temperature
-40°C~85°C TA

Packaging
Tray

Series
Blackfin®

JESD-609 Code
e1

Pbfree Code
no

Part Status
Active

Moisture Sensitivity Level (MSL)
3 (168 Hours)

Number of Terminations
316

Type
Fixed Point

Subcategory
Microprocessors

Technology
CMOS

Terminal Position
BOTTOM

Terminal Form
BALL

Peak Reflow Temperature (Cel)
260

Supply Voltage
1.2V

Terminal Pitch
0.8mm

Frequency
533MHz

Time@Peak Reflow Temperature-Max (s)
40

Pin Count
316

Interface
CAN, SPI, SSP, TWI, UART

Max Supply Voltage
3.6V

Min Supply Voltage
800mV

Memory Size
148kB

RAM Size
32kB

Number of Bits
16

Bit Size
32

Data Bus Width
16b

Address Bus Width
20

Core Architecture
Blackfin

Boundary Scan
YES

Low Power Mode
YES

Voltage - I/O
2.50V 3.30V

Number of UART Channels
3

Barrel Shifter
YES

Internal Bus Architecture
MULTIPLE

Non-Volatile Memory
External

Voltage - Core
1.25V

Length
17mm

Height Seated (Max)
1.7mm

Radiation Hardening
No

RoHS Status
RoHS Compliant

Download datasheets and manufacturer documentation for ADI ADSP-BF538BBCZ-5A.

Datasheets:

analogdevicesinc-adspbf538bbcz5f8-datasheets-3388.pdf

analogdevicesinc-adzsbfllcdezext-datasheets-1771.pdf

ConflictMineralStatement:

analogdeviceslineartechnology-lt5400bhms8e8trpbf-conflictmineralstatement-8771.pdf

ADSP-BF538BBCZ-5A Overview

It is a type of electronic component available in package 316-LFBGA, CSPBGA.There is a packaging method of Tray provided with it.Due to its membership in Fixed Point, it is ideally suited for a wide range of uses.Surface Mount is mounted in a manner that allows it to be moved.The operation of the device at the temperature of -40°C~85°C TA ensures the normal operation of the device.The digital voltage range of 2.50V 3.30V refers to the voltage that can be input or output.The Blackfin® series contains this digital signal processor.Its uses have 316 terminations.The voltage supplied by 1.2V is used to operate it.Pins are available for 316 components.In its configuration, 316 pins can be found.Many related parts can be identified by using the ADSP-BF538 part number as a base.533MHz is a frequency at which the device operates according to a specific design.Surface Mount is used as the mounting method.As a result of its specific characteristics, this device can be classified under the Microprocessors subcategory.800mV is the minimum voltage that can be supplied to this device.This device can be powered by 3.6V voltages.Its memory is capable of storing 148kB data.It is possible to configure the data format and transfer speed of 3 UART channels for synchronous serial communication.A Blackfin-architecture processor core is used here.The device contains 16 pieces of information.

ADSP-BF538BBCZ-5A Features

Supplied in the 316-LFBGA, CSPBGA package

ADSP-BF538BBCZ-5A Applications

There are a lot of Analog Devices Inc.
ADSP-BF538BBCZ-5A DSP applications.

Seismology
Audio
Sonar
Voice recognition
Financial signals
Other sensor array processing
Spectral density estimation
Statistical signal processing
Digital image processing, data compression
Video coding, audio coding
