ADI ADG884BCBZ-REEL7

Manufacturer No:

ADG884BCBZ-REEL7

Manufacturer:

ADI

Package:

10-UFBGA, WLCSP

Description:

50ns, 20ns SPDT 370mOhm BOTTOM Analog Switches BREAK-BEFORE-MAKE ADG884 10 Pins 200pA Typ 2.7V 10-UFBGA, WLCSP

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

ADG884BCBZ-REEL7 information

ADI ADG884BCBZ-REEL7 technical specifications, attributes, parameters and parts with similar specifications to ADI ADG884BCBZ-REEL7.

Type
Parameter

Lifecycle Status
PRODUCTION (Last Updated: 1 month ago)

Factory Lead Time
16 Weeks

Mounting Type
Surface Mount

Package / Case
10-UFBGA, WLCSP

Surface Mount
YES

Number of Pins
10

Operating Temperature
-40°C~85°C TA

Packaging
Tape & Reel (TR)

JESD-609 Code
e1

Pbfree Code
no

Part Status
Active

Moisture Sensitivity Level (MSL)
1 (Unlimited)

Number of Terminations
10

ECCN Code
EAR99

Resistance
370mOhm

Subcategory
Multiplexer or Switches

Max Power Dissipation
5.5?W

Technology
CMOS

Terminal Position
BOTTOM

Terminal Form
BALL

Peak Reflow Temperature (Cel)
260

Number of Functions
2

Supply Voltage
2.7V

Terminal Pitch
0.5mm

Base Part Number
ADG884

Pin Count
10

Number of Outputs
4

Qualification Status
Not Qualified

Operating Supply Voltage
5.5V

Number of Channels
2

Interface
Parallel

Max Supply Voltage
5.5V

Min Supply Voltage
1.8V

Test Frequency
100kHz

Analog IC - Other Type
AUDIO/VIDEO SWITCH

Power Dissipation
5.5?W

Max Supply Current
1?A

Turn On Delay Time
50 ns

Supply Type
Single

Bandwidth
18MHz

Turn-Off Delay Time
20 ns

On-State Resistance (Max)
370mOhm

Multiplexer/Demultiplexer Circuit
2:1

Off-state Isolation-Nom
60 dB

Current - Leakage (IS(off)) (Max)
200pA Typ

Channel Capacitance (CS(off), CD(off))
103pF

On-state Resistance Match-Nom
0.02Ohm

Download datasheets and manufacturer documentation for ADI ADG884BCBZ-REEL7.

ADG884BCBZ-REEL7 Overview

Presented in 10-UFBGA, WLCSP, this electrical component is convenient for overseas shipping. High reliability is ensured by the advanced packaging method Tape & Reel (TR). Surface Mount is where this multiplexer is located. Multiplexer and demultiplexer circuits have a number 2:1. Increasing operating temperature to around -40°C~85°C TA. Totally, there are 10 terminations. A high-quality output is provided by the electrical component's 2 channels. It is safe to turn on and run the electronic component with a 2.7V voltage supply. A total of 10 pins are injected into the electrical part body. A SPDT switching circuit is used for these analog switches. Using the ADG884 search parameter, you can discover variants of the switch. In this multiplexer, the internal resistance is 370mOhm. For details about the functions of 10 pins, please refer to the datasheets. There is Multiplexer or Switches analog multiplexer like this in the world. It is generally not recommended to supply a voltage higher than 5.5V to the switch device in normal circumstances. The digital multiplexer has a low cost Single supply. 1.8V is the lowest voltage the electrical component should receive. An analogue multiplexer drains from a single voltage supply at 1.8V~5.5V. Putting voltage greater than 1?A on the multiplexer may cause damage. It is integrated with a AUDIO/VIDEO SWITCH analog IC. The electrical part can be operated at 5.5V voltage levels. The data can be transferred over a wide range of bandwidths, called 18MHz bandwidths. In this digital multiplexer, there are 4 outputs.

ADG884BCBZ-REEL7 Features

2 Channels
Switch Circuit: SPDT
Bandwidth: 18MHz

ADG884BCBZ-REEL7 Applications

There are a lot of Analog Devices Inc.
ADG884BCBZ-REEL7 Analog Switches & Multiplexers ICs applications.

Precision data acquisition
Battery-powered systems
Sample-and-hold systems
Communication systems
Data Acquisition Systems
Relay Replacement
Battery Powered Systems
Existing multiplexer applications (both fault-protected and nonfault-protected)
New designs requiring multiplexer functions
Cellular phones
