ADI AD8634HFZ
ADI AD8634HFZ

ADI AD8634HFZ

Manufacturer No:

AD8634HFZ

Manufacturer:

ADI

Package:

8-CFlatpack

Description:

70mA per Channel 40nA 115 dB Instrumentational OP Amps 3V~30V ±1.5V~15V AD8634 8 Pins 8-CFlatpack

Delivery:

DHL
DHL
DHL
DHL

Payment:

DHL
DHL
DHL
DHL
DHL
DHL
DHL

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

AD8634HFZ information

ADI AD8634HFZ technical specifications, attributes, parameters and parts with similar specifications to ADI AD8634HFZ.

  • Type
  • Parameter
  • Lifecycle Status
  • PRODUCTION (Last Updated: 1 week ago)
  • Factory Lead Time
  • 10 Weeks
  • Contact Plating
  • Gold
  • Mount
  • Surface Mount
  • Mounting Type
  • Surface Mount
  • Package / Case
  • 8-CFlatpack
  • Number of Pins
  • 8
  • Operating Temperature
  • -40°C~210°C
  • Packaging
  • Tube
  • JESD-609 Code
  • e4
  • Pbfree Code
  • no
  • Part Status
  • Active
  • Moisture Sensitivity Level (MSL)
  • 1 (Unlimited)
  • ECCN Code
  • EAR99
  • Subcategory
  • Operational Amplifier
  • Technology
  • BIPOLAR
  • Terminal Position
  • DUAL
  • Peak Reflow Temperature (Cel)
  • NOT APPLICABLE
  • Number of Functions
  • 2
  • Supply Voltage
  • 15V
  • Time@Peak Reflow Temperature-Max (s)
  • NOT SPECIFIED
  • Base Part Number
  • AD8634
  • Pin Count
  • 8
  • Qualification Status
  • Not Qualified
  • Number of Circuits
  • 2
  • Operating Supply Current
  • 1.1mA
  • Nominal Supply Current
  • 1.1mA
  • Quiescent Current
  • 1.1mA
  • Slew Rate
  • 5V/?s
  • Architecture
  • VOLTAGE-FEEDBACK
  • Amplifier Type
  • General Purpose
  • Common Mode Rejection Ratio
  • 115 dB
  • Current - Input Bias
  • 40nA
  • Voltage - Supply, Single/Dual (±)
  • 3V~30V ±1.5V~15V
  • Output Current per Channel
  • 70mA
  • Input Offset Voltage (Vos)
  • 250?V
  • Bandwidth
  • 9.7MHz
  • Neg Supply Voltage-Nom (Vsup)
  • -15V
  • Unity Gain BW-Nom
  • 9700 kHz
  • Voltage Gain
  • 108dB
  • Power Supply Rejection Ratio (PSRR)
  • 113dB
  • Low-Offset
  • YES
  • Frequency Compensation
  • YES
  • -3db Bandwidth
  • 4.9MHz
  • Number of Amplifiers
  • 1
  • Length
  • 6.477mm
  • REACH SVHC
  • No SVHC

Download datasheets and manufacturer documentation for ADI AD8634HFZ.

Datasheets:

ConflictMineralStatement:

AD8634HFZ Overview


In the package, you will find a 8-CFlatpack-case to contain the op amp ic. The instrumentation amplifier in this picture is of the General Purpose-type. A Tube case is used for delivering the op amp. A total of 8 pins are located on this board. This linear amplifier should be powered by an 15V battery. This particular linear amplifier is a type of Operational Amplifier device, to be precise. The op amp ic has an array of 8 pins on it. Op amp rates 250?V as input offset voltage. For this electrical component, Surface Mount is the recommended mounting type. According to the manufacturer, this buffer op amp works well at -40°C~210°C , which is a good operating temperature. Using an 1.1mA supply current, this operational amplifier ics can be operated. You should keep the voltage gain at 108dB for the time being. A instrumentation amplifier like this has 2 circuits. Buffer amplifier produces Rail-to-Rail signals, which is one of its many benefits. The current is quiescent at 1.1mA. The buffer amplifier consists of 1 amplifiers.

AD8634HFZ Features


8 Pins
supply voltage of 15V
108dB voltage gain
Output Type: Rail-to-Rail


AD8634HFZ Applications


There are a lot of Analog Devices Inc.
AD8634HFZ Instrumentational OP Amps applications.


  • Multiplication circuits
  • Division circuits
  • Precision measurement
  • Power control
  • Information processing
  • Weak signal detection
  • Signal amplification
  • Signal filtering
  • Signal operation
  • Video computer boards
