KEYSTONE 976
Manufacturer No:
976
Manufacturer:
Package:
Description:
1-Row Header Solder Copper Alloy Tape & Reel (TR) Surface Mount, Right Angle Tin Polyamide (PA66), Nylon 6/6 3-Position Board to Cable/Wire 0.224 5.69mm Height
Quantity:
Delivery:
Payment:
In Stock :Available
Price not displayed? Please send an RFQ, and we will respond immediately.
976 information
KEYSTONE 976 technical specifications, attributes, parameters and parts with similar specifications to KEYSTONE 976.
- Type
- Parameter
- Factory Lead Time
- 6 Weeks
- Contact Material
- Copper Alloy
- Mounting Type
- Surface Mount, Right Angle
- Contact Shape
- Square
- Insulation Material
- Polyamide (PA66), Nylon 6/6
- Packaging
- Tape & Reel (TR)
- Feature
- Board Guide
- Part Status
- Active
- Moisture Sensitivity Level (MSL)
- 1 (Unlimited)
- Termination
- Solder
- ECCN Code
- EAR99
- Connector Type
- Header
- Number of Positions
- 3
- Number of Rows
- 1
- Voltage - Rated
- 250V
- Fastening Type
- Latch Holder
- Contact Finish - Mating
- Tin
- Contact Type
- Male Pin
- Current Rating (Amps)
- 3A
- Insulation Height
- 0.224 5.69mm
- Style
- Board to Cable/Wire
- Number of Positions Loaded
- All
- Pitch - Mating
- 0.079 2.00mm
- Insulation Color
- Natural
- Material Flammability Rating
- UL94 V-0
- RoHS Status
- RoHS Compliant
Download datasheets and manufacturer documentation for KEYSTONE 976.
Datasheets:
Environmental Information:
976 Overview
Currently, it is packaged in Header.The mounting type of the device is Surface Mount, Right Angle.A Tape & Reel (TR) case is used to package the product.A number of features make the Board Guide feature more powerful.
976 Features
976 Applications
There are a lot of Keystone Electronics
976 Rectangular Connectors applications.
- Embedded systems
- Datacom
- Communication
- Medical technology
- Military Technology
- Measuring & Control Technology
- Instrumentation
- Automotive Electronics
- Telecommunications
- Data Technology
