Renesas 82V2048SDAG
Renesas 82V2048SDAG

Renesas 82V2048SDAG

Manufacturer No:

82V2048SDAG

Manufacturer:

Renesas

Package:

LQFP

Description:

144 Terminations 3.3V 144 Pin Telecom device 1 Functions Min 3.13V V Max 3.47V V

Delivery:

DHL
DHL
DHL
DHL

Payment:

DHL
DHL
DHL
DHL
DHL
DHL
DHL

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

82V2048SDAG information

Renesas 82V2048SDAG technical specifications, attributes, parameters and parts with similar specifications to Renesas 82V2048SDAG.

  • Type
  • Parameter
  • Mount
  • Surface Mount
  • Package / Case
  • LQFP
  • Number of Pins
  • 144
  • Published
  • 2012
  • JESD-609 Code
  • e3
  • Pbfree Code
  • yes
  • Moisture Sensitivity Level (MSL)
  • 3 (168 Hours)
  • Number of Terminations
  • 144
  • ECCN Code
  • EAR99
  • Terminal Finish
  • Matte Tin (Sn) - annealed
  • Max Operating Temperature
  • 85°C
  • Min Operating Temperature
  • -40°C
  • Subcategory
  • Digital Transmission Interfaces
  • Terminal Position
  • QUAD
  • Terminal Form
  • GULL WING
  • Peak Reflow Temperature (Cel)
  • 260
  • Number of Functions
  • 1
  • Supply Voltage
  • 3.3V
  • Terminal Pitch
  • 0.5mm
  • Time@Peak Reflow Temperature-Max (s)
  • 30
  • Pin Count
  • 144
  • Qualification Status
  • Not Qualified
  • Operating Supply Voltage
  • 3.3V
  • Power Supplies
  • 3.33.3/5V
  • Max Supply Voltage
  • 3.47V
  • Min Supply Voltage
  • 3.13V
  • Operating Supply Current
  • 55mA
  • Max Supply Current
  • 65mA
  • Data Rate
  • 2.048 Mbps
  • Telecom IC Type
  • PCM TRANSCEIVER
  • Number of Transceivers
  • 8
  • Length
  • 20mm
  • Height Seated (Max)
  • 1.6mm
  • Width
  • 20mm
  • RoHS Status
  • RoHS Compliant

Download datasheets and manufacturer documentation for Renesas 82V2048SDAG.

Datasheets:

82V2048SDAG Overview


The LQFP package reduces the amount of space on a board.A Surface Mount-axis mounts telecom switching.As part of its configuration, it includes 144 terminations.It requires a supply voltage of 3.3V.An interface with 144 pins is present on this telecom interface.Telecom ICs are of type PCM TRANSCEIVER.With the voltage of 3.3V as its supply voltage, designers have a great deal of flexibility.Designers benefit from great flexibility since it works with the 55mA supply current.Among Digital Transmission Interfaces's subcategories, telecommunications device falls.As a precaution, the temperature is set at a minimum value of -40°C in order to ensure normal operation.85°C is set to the maximum value to ensure normal operation.In the design phase, telecommunications device is configured wtelecommunications device h 1 functions.Voltage supplied should be 3.13V at least.There should be a voltage supply that is lower than 3.47V.Its pin configuration is determined by 144 telecom product pins.If you want to keep the supply current at 65mA, you should do so.Telecommunication tools consists of 8-transceivers.

82V2048SDAG Features


Available in the LQFP package
PCM TRANSCEIVER as telecom IC type
Operating supply voltage of 3.3V
Operating supply current of 55mA
8 transceivers


82V2048SDAG Applications


There are a lot of Integrated Device Technology (IDT)
82V2048SDAG Telecom applications.


  • BITS Timing
  • Digital Access Cross-connect System (DACs)
  • Digital Cross-connect Systems (DCS)
  • Frame Relay Switches and Access Devices (FRADS)
  • ISDN Primary Rate Interfaces (PRA)
  • PBXs channel bank
  • PCM channel bank
  • T3 channelized access concentrators
  • M13 MUX
  • Wireless base stations
