NEXPERIA 74HC393BQ,115

Manufacturer No:

74HC393BQ,115

Manufacturer:

NEXPERIA

Package:

14-VFQFN Exposed Pad

Description:

2 Element 5V CMOS QUAD Counters & Dividers 74HC Series 74HC393 14 Pins Up Negative Edge 14-VFQFN Exposed Pad

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

74HC393BQ,115 information

NEXPERIA 74HC393BQ,115 technical specifications, attributes, parameters and parts with similar specifications to NEXPERIA 74HC393BQ,115.

Type
Parameter

Factory Lead Time
8 Weeks

Contact Plating
Gold

Mount
Surface Mount

Mounting Type
Surface Mount

Package / Case
14-VFQFN Exposed Pad

Number of Pins
14

Operating Temperature
-40°C~125°C

Packaging
Tape & Reel (TR)

Series
74HC

Published
2013

JESD-609 Code
e4

Part Status
Active

Moisture Sensitivity Level (MSL)
1 (Unlimited)

Number of Terminations
14

Technology
CMOS

Voltage - Supply
2V~6V

Terminal Position
QUAD

Peak Reflow Temperature (Cel)
260

Number of Functions
2

Supply Voltage
5V

Terminal Pitch
0.5mm

Time@Peak Reflow Temperature-Max (s)
30

Base Part Number
74HC393

Pin Count
14

Number of Elements
2

Supply Voltage-Max (Vsup)
6V

Supply Voltage-Min (Vsup)
2V

Propagation Delay
210 ns

Quiescent Current
8?A

Turn On Delay Time
210 ns

Reset
Asynchronous

Family
HC/UH

Logic Function
Counter

Direction
Up

Logic Type
Binary Counter

Number of Bits per Element
4

Trigger Type
Negative Edge

Clock Edge Trigger Type
Negative Edge

Count Rate
107MHz

Length
3mm

Height Seated (Max)
1mm

Radiation Hardening
No

RoHS Status
RoHS Compliant

Download datasheets and manufacturer documentation for NEXPERIA 74HC393BQ,115.

74HC393BQ,115 Overview

This is a device supplied in the 14-VFQFN Exposed Pad package. There are 14terminations used for configuring it. The supply voltage of 5V permits it to operate with full flexibility. There are 2 terminations on the device. There are a total of 14 pins in all components. As a result, it is packaged as Tape & Reel (TR). As part of the circuit, there are 14pins used to connect other components. It is mounted in the direction of [0]. The HC/UHfamily is derived from it. Having been designed as a member of the 74HCseries, it is well suited for use in a wide range of applications. Binary Counteris selected as the logic type. In this case, the operating temperature should be set to -40°C~125°C. Having a mounting type of [0], it is suitable for installation. By providing the supply voltage of [0], it is capable of operating more reliably. The array stores 4bits in each element. There are more related parts under the 74HC393base part number. The device operates on a supply voltage of [0]. There is 2V minimum supply voltage (Vsup) for this device. It is possible to reach a maximum supply voltage of 6VV (Vsup). In the state of [0], it consumes quiescent current.

74HC393BQ,115 Features

Embedded in the 14-VFQFN Exposed Pad package
4 bits per element
Operating supply voltage of 5V

74HC393BQ,115 Applications

There are a lot of Nexperia USA Inc.
74HC393BQ,115 Counters & Dividers applications.

Frequency dividing circuits
Time delay circuits
Communications Digital Frequency Synthesizers;
VHF, UHF, FM, AM, etc.
Fixed or Programmable Frequency Division
Time Out Timer for Consumer-Application Industrial Controls
Timing applications
Clocks
Up Counters
Dual Up Counters
