ZL30155GGG2 Information

Microchip ZL30155GGG2 technical specifications, attributes, parameters and parts with similar specifications to Microchip ZL30155GGG2.

  • Type
  • Parameter
  • Type
  • Multi-Channel
  • Inputs
  • 4 D/SE
  • CMOS Outputs
  • 4
  • Low-Jitter Synthesizers
  • 2
  • Typical Jitter (12kHz-20MHz) fs RMS
  • 700
  • Diff InputFreq. Range
  • 1 kHz-750 MHz
  • Output Freq Range
  • 1 kHz-750 MHz
  • Type
  • Parameter

Download datasheets and manufacturer documentation for Microchip ZL30155GGG2.

Data Sheets:

The ZL30155 Dual Channel Universal Clock Translator, part of Microchip's ClockCenter platform of Synchronous Clock devices, delivers industry leading synchronization performance for high-speed complex applications.  The highly integrated and programmable solution provides translation from any input reference frequency to any output clock frequency with jitter performance that can directly drive 10 G PHY devices.
The ZL30155 integrates 2 independent digital PLLs, accepts 4 input references and generates 12 programmable clock outputs.  The highly integrated solution allows designers to replace multiple components with a single chip, simplifying design and reducing component count and power.

  • Two independent clock channels
  • Programmable synthesizers generate any clock-rate from 1 kHz to 720 MHz
  • Two precision synthesizers generate clocks with jitter below 0.7ps RMS for 10 G PHYs
  • Programmable digital PLLs synchronize to any clock rate from 1 kHz to 720 MHz
  • Flexible two-stage architecture translates between arbitrary data rates, line coding rates and FEC rates
  • Digital PLLs filter jitter from 14 Hz, 28 Hz, 56 Hz, 112 Hz, 224 Hz, 448 Hz or 896 Hz
  • Automatic hitless reference switching and digital holdover on reference fail
  • Four reference inputs configurable as single ended or differential
  • Eight LVPECL outputs and four LVCMOS outputs
  • Operates from a single crystal resonator or clock oscillator
  • Customer defined default configuration, including input/output frequencies, is available via OTP (One Time Programmable) memory
  • Configurable via SPI/I2C interface
      • Applications/Uses
    • - 10 Gigabit linecards
    • - Synchronous Ethernet, 10GBASE-R and 10GBASE-W
    • - OTN multiplexers and transponders
    • - SONET/SDH, Fibre Channel, XAUI
