MAXLINEAR XR17D158IV

Manufacturer No:

XR17D158IV

Manufacturer:

MAXLINEAR

Package:

LQFP

Description:

5V V 1.6mm mm 20mm mm Interface - UARTs (Universal Asynchronous Receiver Transmitter) 20mm mm CMOS 144 NOT SPECIFIED 144

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

XR17D158IV information

MAXLINEAR XR17D158IV technical specifications, attributes, parameters and parts with similar specifications to MAXLINEAR XR17D158IV.

Type
Parameter

Mount
Surface Mount

Package / Case
LQFP

Number of Pins
144

JESD-609 Code
e0

Number of Terminations
144

Terminal Finish
Tin/Lead (Sn/Pb)

Max Operating Temperature
85°C

Min Operating Temperature
-40°C

Additional Feature
ALSO REQUIRES 3.3V SUPPLY

Subcategory
Serial IO/Communication Controllers

Technology
CMOS

Terminal Position
QUAD

Terminal Form
GULL WING

Peak Reflow Temperature (Cel)
NOT SPECIFIED

Supply Voltage
5V

Terminal Pitch
0.5mm

Time@Peak Reflow Temperature-Max (s)
NOT SPECIFIED

Pin Count
144

Qualification Status
Not Qualified

Operating Supply Voltage
5V

Temperature Grade
INDUSTRIAL

Number of Channels
8

Max Supply Voltage
5.5V

Min Supply Voltage
4.5V

uPs/uCs/Peripheral ICs Type
SERIAL IO/COMMUNICATION CONTROLLER, SERIAL

Clock Frequency
50MHz

Data Rate
6.25 Mbps

Address Bus Width
32

Boundary Scan
NO

Low Power Mode
YES

External Data Bus Width
32

Number of Serial I/Os
8

Bus Compatibility
PCI

Communication Protocol
ASYNC, BIT

Data Encoding/Decoding Method
NRZ

Length
20mm

Height Seated (Max)
1.6mm

Width
20mm

RoHS Status
RoHS Compliant

Lead Free
Contains Lead

Download datasheets and manufacturer documentation for MAXLINEAR XR17D158IV.

XR17D158IV Overview

UART is available in the cost-effective LQFP package.There are 8 channels used for transmission.SERIAL IO/COMMUNICATION CONTROLLER, SERIAL is used as its uPs/uCs/Peripheral ICs type.144 terminations are used as parts of its configuration.The supply voltage of 5V is provided for its operation.There are 8 serial I/Os working as a way for data communication.This electronic device is a type of 144-pin IC.The clock frequency of this IC is measured at 50MHz.Due to a series of similarities, it is included into the subcategory of Serial IO/Communication Controllers.The operating temperature should not exceed -40°C to ensure normal work for a long time.The operating temperature should be in excess of 85°C to ensure the normal work for a long time.144 pins are designed to form the basis of its configuration.UART is mounted in the way of Surface Mount.Reliability can be ensured when the supply voltage is kept below 5.5V.Reliability can be ensured when the supply voltage is kept above 4.5V.The supply voltage of 5V is provided for its high-efficiency operation.Moreover, it is also able to perform ALSO REQUIRES 3.3V SUPPLY.

XR17D158IV Features

8 serial I/Os
Clock frequency of 50MHz
Operating supply voltage of 5V
ALSO REQUIRES 3.3V SUPPLY

XR17D158IV Applications

There are a lot of Exar Corporation
XR17D158IV UARTs applications.

Factory automation and process control
Portable and battery operated devices
Cellular data devices
Industrial computing
Communications equipment
White goods
Battery Operated Electronics
Handheld Terminal
Personal Digital Assistants
Cellular Phones DataPort
