AMD XC7A200T-3FFG1156E

Manufacturer No:

XC7A200T-3FFG1156E

Manufacturer:

AMD

Package:

1156-BBGA, FCBGA

Description:

3.1mm mm 110 ps ns 1GB B FPGAs Artix-7 Series 1156-BBGA, FCBGA 1mm mm

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

XC7A200T-3FFG1156E information

AMD XC7A200T-3FFG1156E technical specifications, attributes, parameters and parts with similar specifications to AMD XC7A200T-3FFG1156E.

Type
Parameter

Factory Lead Time
10 Weeks

Contact Plating
Copper, Silver, Tin

Mounting Type
Surface Mount

Package / Case
1156-BBGA, FCBGA

Surface Mount
YES

Operating Temperature
0°C~100°C TJ

Packaging
Tray

Series
Artix-7

Published
2009

JESD-609 Code
e1

Pbfree Code
yes

Part Status
Active

Moisture Sensitivity Level (MSL)
4 (72 Hours)

ECCN Code
3A991.D

Terminal Finish
Tin/Silver/Copper (Sn96.5Ag3.0Cu0.5)

HTS Code
8542.39.00.01

Subcategory
Field Programmable Gate Arrays

Technology
CMOS

Voltage - Supply
0.95V~1.05V

Terminal Position
BOTTOM

Terminal Form
BALL

Supply Voltage
1V

Terminal Pitch
1mm

Base Part Number
XC7A200T

Number of Outputs
500

Power Supplies
1V

Memory Size
1GB

Number of I/O
500

RAM Size
1.6MB

Memory Type
DDR3

Clock Frequency
1412MHz

Propagation Delay
110 ps

Turn On Delay Time
110 ps

Number of Inputs
500

Programmable Logic Type
FIELD PROGRAMMABLE GATE ARRAY

Number of Logic Elements/Cells
215360

Total RAM Bits
13455360

Number of LABs/CLBs
16825

Speed Grade
-3

Number of Registers
269200

Combinatorial Delay of a CLB-Max
0.94 ns

Length
35mm

Height Seated (Max)
3.1mm

Width
35mm

Radiation Hardening
No

RoHS Status
RoHS Compliant

Download datasheets and manufacturer documentation for AMD XC7A200T-3FFG1156E.

XC7A200T-3FFG1156E Overview

In the 1156-BBGA, FCBGA package, you will find fpga chips. An FPGA of this type is made up of FIELD PROGRAMMABLE GATE ARRAY gates. The device has 500 I/O ports for more coherent data transfer. To form a fundamental building block, there are 215360 logic elements/cells. In order to operate fpga chips, a voltage supply of 1V volts is required. FPGA parts like this belong to the Field Programmable Gate Arrays family. Surface Mount-connectors can be used to attach this FPGA module to the development board. There is a 0.95V~1.05V-volt supply voltage required for the device to operate. The Artix-7 Series is one of the types of FPGAs that belong to this type. As far as the operating temperature is concerned, it should be kept within 0°C~100°C TJ when operating. A total of 500 outputs are incorporated into this device. Unlike other FPGA models, this one is contained in Tray for the sake of space saving. Fpga chips is important to note that this device has a RAM capacFpga chipsy of 13455360 bFpga chipss. You can find related parts by using the part number XC7A200T, which is its base part number. It is crucial that the RAM si1.6MBe of this FPGA module reaches 1.6MB so that the program can run normally. A total of 16825 LABs/CLBs are included in this FPGA. There is a 1V power supply that is required to operate it. It usually uses a 1412MHz crystal. For storing programs and data, this FPGA module embeds memory 1GB. Fpga semiconductor is important to note that the data is stored and transferred in 269200 different registers. Adapted for storing data, the DDR3 memory avoids resource conflicts.

XC7A200T-3FFG1156E Features

500 I/Os
Up to 13455360 RAM bits
269200 registers

XC7A200T-3FFG1156E Applications

There are a lot of Xilinx Inc.
XC7A200T-3FFG1156E FPGAs applications.

Software-defined radio
Random logic
ASIC prototyping
Medical imaging
Computer hardware emulation
Integrating multiple SPLDs
Voice recognition
Cryptography
Filtering and communication encoding
Aerospace and Defense
