AMD XC3S400AN-5FTG256C

Manufacturer No:

XC3S400AN-5FTG256C

Manufacturer:

AMD

Package:

256-LBGA

Description:

1.2V V FPGAs Spartan®-3AN Series 256-LBGA 1mm mm 256

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

XC3S400AN-5FTG256C information

AMD XC3S400AN-5FTG256C technical specifications, attributes, parameters and parts with similar specifications to AMD XC3S400AN-5FTG256C.

Type
Parameter

Factory Lead Time
16 Weeks

Mount
Surface Mount

Mounting Type
Surface Mount

Package / Case
256-LBGA

Number of Pins
256

Operating Temperature
0°C~85°C TJ

Packaging
Tray

Series
Spartan®-3AN

Published
2012

JESD-609 Code
e1

Part Status
Active

Moisture Sensitivity Level (MSL)
3 (168 Hours)

Number of Terminations
256

ECCN Code
EAR99

Terminal Finish
Tin/Silver/Copper (Sn/Ag/Cu)

Subcategory
Field Programmable Gate Arrays

Technology
CMOS

Voltage - Supply
1.14V~1.26V

Terminal Position
BOTTOM

Terminal Form
BALL

Peak Reflow Temperature (Cel)
260

Supply Voltage
1.2V

Terminal Pitch
1mm

Time@Peak Reflow Temperature-Max (s)
30

Pin Count
256

Number of Outputs
160

Qualification Status
Not Qualified

Operating Supply Voltage
1.2V

Power Supplies
1.21.2/3.33.3V

Number of I/O
195

RAM Size
45kB

Clock Frequency
770MHz

Propagation Delay
4.36 ns

Programmable Logic Type
FIELD PROGRAMMABLE GATE ARRAY

Number of Logic Elements/Cells
8064

Total RAM Bits
368640

Number of Gates
400000

Speed Grade
5

Number of Registers
896

Combinatorial Delay of a CLB-Max
0.62 ns

Number of CLBs
896

Length
17mm

Width
17mm

RoHS Status
RoHS Compliant

Download datasheets and manufacturer documentation for AMD XC3S400AN-5FTG256C.

XC3S400AN-5FTG256C Overview

A 256-LBGA package is provided with this component. FPGAs of this type consist of FIELD PROGRAMMABLE GATE ARRAY components. This device features 195 I/Os in order to transfer data in a more efficient manner. A fundamental building block is made up of 8064 logic elements/cells. An electrical supply voltage of 1.2V powers it. A Field Programmable Gate Arrays-series FPGA part. An FPGA module can be attached to a development board with a Surface Mount-pin. Powered by a 1.14V~1.26V supply voltage, fpga chips is able to operate at high speeds. The FPGA belongs to the Spartan®-3AN series of FPGAs, and it is one type of FPGA. During the operation of the system, the operating temperature should remain within the range of 0°C~85°C TJ. In order to make this device as versatile as possible, there are 160 different outputs included. It is for space saving reasons that this FPGA model is contained in Tray. As a whole, it has 256 terminations. The RAM bits that are offered by this fpga chips are 368640. Related parts can be found by using its base part number XC3S400AN. The FPGA module's RAM si45kBe reaches 45kB in order to ensure that the program operates in a normal manner. 256 pins are designed into the device. As long as this FPGA is mounted in Surface Mount, it should be able to function as it should in terms of its specifications, as well as its capabilities. A 1.2V-volt supply allows designers to fully utilize its flexibility. Powered by a 1.21.2/3.33.3V power supply, it can be operated by almost anyone. Among its basic building blocks, there are 400000 gates that are included in it. In addition to this, it has 256 pins. Normally, fpga semiconductor uses an oscillator, which oscillates at 770MHz, to create the signal. As a result, there are 896 registers which are used to store and transfer data. In its architecture, there are 896 CLB modules.
