TOREX XC3202B183ZR-G

Manufacturer No:

XC3202B183ZR-G

Manufacturer:

TOREX

Package:

6-UDFN Exposed Pad

Description:

XC3202B Series Push-Pull 2.4V~5.5V -40°C~85°C TA Omnipolar Switch North Pole, South Pole ±4mT Trip, 0mT Release 16?A-Supply (Max) 6-UDFN Exposed Pad

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

XC3202B183ZR-G information

TOREX XC3202B183ZR-G technical specifications, attributes, parameters and parts with similar specifications to TOREX XC3202B183ZR-G.

Type
Parameter

Factory Lead Time
10 Weeks

Mounting Type
Surface Mount

Package / Case
6-UDFN Exposed Pad

Surface Mount
YES

Operating Temperature
-40°C~85°C TA

Packaging
Tape & Reel (TR)

Series
XC3202B

Published
2010

Part Status
Active

Moisture Sensitivity Level (MSL)
1 (Unlimited)

Number of Terminations
6

Subcategory
Other Sensors

Technology
Hall Effect

Voltage - Supply
2.4V~5.5V

Function
Omnipolar Switch

Current - Supply (Max)
16?A

Output Type
Push-Pull

Max Output Current
40mA

Power Supplies
3V

Polarization
North Pole, South Pole

Max Supply Current
16?A

Sensing Method
Hall Effect

Test Condition
25°C

Sensing Range
±4mT Trip, 0mT Release

Magnetic Field Range-Max
4 mT

RoHS Status
RoHS Compliant

Download datasheets and manufacturer documentation for TOREX XC3202B183ZR-G.

XC3202B183ZR-G Overview

Designed to protect magnetic switches from damage, the Tape & Reel (TR) package contains the switches. In order to ensure safety, magnetic switches are packaged in 6-UDFN Exposed Pad packages. In order to function well, magnetic switches should be able to supply a maximum current of 16?A. The maximum current these switches can supply when they work is 40mA. Normally, these switches supply 16?A current. This termination has 6 terminations.

XC3202B183ZR-G Features

Packaging: Tape & Reel (TR)
Moisture Sensitivity Level (MSL): 1 (Unlimited)
Supply Voltage: 2.4V~5.5V
Operating Temperature: -40°C~85°C TA
Mounting Type: Surface Mount
6 Terminations
Output Type: Push-Pull
Maximum Supply Current: 16?A

XC3202B183ZR-G Applications

There are a lot of Torex Semiconductor Ltd
XC3202B183ZR-G Magnetic Switches applications.

Robotics control
Electric window lift
Convertible roof position
Motor assemblies
Medication dispensing control
Security and military applications
Detection of ferromagnetic
Discrimination of ferromagnetic
Localization of ferromagnetic
Conducting objects
