TI X5LS20216ASZWTQQ1

Manufacturer No:

X5LS20216ASZWTQQ1

Manufacturer:

Package:

337-LFBGA

Description:

2MB 2M x 8 FLASH ARM® Cortex®-R4F 16/32-Bit Microcontroller Automotive, AEC-Q100, Hercules™ TMS570 ARM® Cortex®-R Series 5LS20216 337 Pin 160MHz 1.5V 337-LFBGA

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

X5LS20216ASZWTQQ1 information

TI X5LS20216ASZWTQQ1 technical specifications, attributes, parameters and parts with similar specifications to TI X5LS20216ASZWTQQ1.

Type
Parameter

Mount
Surface Mount

Mounting Type
Surface Mount

Package / Case
337-LFBGA

Number of Pins
337

Operating Temperature
-40°C~125°C TA

Packaging
Tray

Series
Automotive, AEC-Q100, Hercules™ TMS570 ARM® Cortex®-R

Part Status
Obsolete

Moisture Sensitivity Level (MSL)
3 (168 Hours)

Number of Terminations
337

HTS Code
8542.31.00.01

Subcategory
Microcontrollers

Technology
CMOS

Terminal Position
BOTTOM

Terminal Form
BALL

Supply Voltage
1.5V

Terminal Pitch
0.8mm

Frequency
160MHz

Base Part Number
5LS20216

Pin Count
337

Operating Supply Voltage
3.3V

Supply Voltage-Max (Vsup)
1.65V

Interface
CAN, EBI/EMI, LIN, SCI, SPI, UART, USART

Memory Size
2MB

Number of I/O
115

RAM Size
160K x 8

Voltage - Supply (Vcc/Vdd)
1.35V~1.65V

uPs/uCs/Peripheral ICs Type
MICROCONTROLLER, RISC

Core Processor
ARM® Cortex®-R4F

Peripherals
DMA, POR

Program Memory Type
FLASH

Core Size
16/32-Bit

Program Memory Size
2MB 2M x 8

Connectivity
CANbus, EBI/EMI, LINbus, SCI, SPI, UART/USART

Supply Current-Max
550mA

Bit Size
32

Data Converter
A/D 24x12b

Has ADC
YES

DMA Channels
YES

Data Bus Width
16b

PWM Channels
NO

DAC Channels
NO

Number of Timers/Counters
32

Address Bus Width
22

ROM (words)
2097152

Core Architecture
ARM

CPU Family
CORTEX-R4F

Download datasheets and manufacturer documentation for TI X5LS20216ASZWTQQ1.

X5LS20216ASZWTQQ1 Overview

A 337-LFBGA package is included. In total, it has 115 inputs and outputs. This Microcontroller is mounted using the Surface Mount mounting type. Powered by the 16/32-Bit core, it offers a wide range of capabilities. The type of memory that the program uses is FLASH. The temperature range of this Microcontroller is within the range of -40°C~125°C TA. Automotive, AEC-Q100, Hercules™ TMS570 ARM® Cortex®-R series components belong to this electrical component. Its program memory size is 2MB 2M x 8. There is a ARM® Cortex®-R4F Core Processor inside MCU that provides this device with its power. MICROCONTROLLER, RISC uPs, uCs, and peripheral ICs make up the Microcontroller. Microcontroller is known that the chip has 337 terminations in total. The part works on a 32-bit basis. An output voltage of 1.5V volts is available for this Microcontroller chip. The Microcontroller chip has YES DMA channels. 2MB memory size belongs to the part. 5LS20216 is the base part number that you can use to find alternatives. A good performance can be achieved at a frequency of 160MHz, as long as it is operated at a low power consumption. In order for the device to work with the motor, it utilizes the PWM channel NO. On the chip, there are 337 pins that are accessible. A total of 32 timers/counters are included in the package. A total of 337 pins are present. Devices based on the CORTEX-R4F series of CPUs are embedded in the device. It is built on a ARM core architecture.
