SKYWORKS WT41U-E-AI56

Manufacturer No:

WT41U-E-AI56

Manufacturer:

SKYWORKS

Package:

Module

Description:

2.4GHz Bluetooth -40°C~85°C 3.3V SPI, UART, USB Tape & Reel (TR) Antenna Not Included, U.FL 3 Mbps 17dBm Bluetooth v2.1 + EDR -94dBm Module

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

WT41U-E-AI56 information

SKYWORKS WT41U-E-AI56 technical specifications, attributes, parameters and parts with similar specifications to SKYWORKS WT41U-E-AI56.

Type
Parameter

Factory Lead Time
12 Weeks

Mounting Type
Surface Mount

Package / Case
Module

Surface Mount
YES

Operating Temperature
-40°C~85°C

Packaging
Tape & Reel (TR)

Published
2016

Pbfree Code
yes

Part Status
Active

Moisture Sensitivity Level (MSL)
3 (168 Hours)

Number of Terminations
59

Additional Feature
PITCH TAKEN FROM RECOMMENDED LAND PATTERN

HTS Code
8542.39.00.01

Voltage - Supply
3.3V

Terminal Position
QUAD

Terminal Form
NO LEAD

Peak Reflow Temperature (Cel)
NOT SPECIFIED

Number of Functions
1

Terminal Pitch
1.5mm

Frequency
2.4GHz

Time@Peak Reflow Temperature-Max (s)
NOT SPECIFIED

JESD-30 Code
R-XQMA-N59

Supply Voltage-Max (Vsup)
3.6V

Supply Voltage-Min (Vsup)
3V

Protocol
Bluetooth v2.1 + EDR

Power - Output
17dBm

RF Family/Standard
Bluetooth

Antenna Type
Antenna Not Included, U.FL

Consumer IC Type
CONSUMER CIRCUIT

Sensitivity
-94dBm

Serial Interfaces
SPI, UART, USB

Current - Receiving
44mA

Current - Transmitting
85mA

Length
35.3mm

Height Seated (Max)
2.45mm

Width
14mm

RoHS Status
RoHS Compliant

Download datasheets and manufacturer documentation for SKYWORKS WT41U-E-AI56.

Datasheets:

siliconlabs-wt41uahci21001-datasheets-5958.pdf

WT41U-E-AI56 Overview

RF Transceiver' mounting is done according to the Surface Mount method.There is an optimized performance in this RF Transceiver module because it utilizes the Tape & Reel (TR) package.This RF Transceiver module has 59 terminations.Operating at -40°C~85°C is the recommended temperature for Transceiver's operation.RF Transceivers with 3.3V voltage capabilities can be used.2.4GHz is the frequency of the RF Transceiver Module.

WT41U-E-AI56 Features

Surface Mount
Tape & Reel (TR) package
59 terminations
3.3V volts

WT41U-E-AI56 Applications

There are a lot of Silicon Labs
WT41U-E-AI56 RF Transceiver Modules applications.

Receive
Switch
Power management
Internet of Things (IoT)
Secure Payment
Home and Security
Health and Fitness
Industrial and Data Logger
LED Lighting
Utility and Smart Energy

User Guide
