ADI VT1697SBFQR

Manufacturer No:

VT1697SBFQR

Manufacturer:

ADI

Package:

16-VFQFN

Description:

Tape & Reel (TR) 16-VFQFN PWM 1.71V~1.98V Surface Mount -40°C~125°C TJ General Purpose Half Bridge Inductive 8.5V~14V

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

VT1697SBFQR information

ADI VT1697SBFQR technical specifications, attributes, parameters and parts with similar specifications to ADI VT1697SBFQR.

Type
Parameter

Mounting Type
Surface Mount

Package / Case
16-VFQFN

Supplier Device Package
16-FCQFN (6x3.75)

Operating Temperature
-40°C~125°C TJ

Packaging
Tape & Reel (TR)

Feature
Diode Emulation, Status Flag

Part Status
Obsolete

Moisture Sensitivity Level (MSL)
1 (Unlimited)

Applications
General Purpose

Technology
Power MOSFET

Voltage - Supply
1.71V~1.98V

Interface
PWM

Output Configuration
Half Bridge

Voltage - Load
8.5V~14V

Fault Protection
Current Limiting, Over Temperature, Short Circuit, UVLO

Current - Peak Output
55A

Load Type
Inductive

RoHS Status
RoHS Compliant

Download datasheets and manufacturer documentation for ADI VT1697SBFQR.

ConflictMineralStatement:

maximintegrated-ds1075z66n-conflictmineralstatement-7504.pdf

VT1697SBFQR Overview

In order to package H bridge, Tape & Reel (TR) is used.H bridge is included in the 16-VFQFN package as a cost-saving measure.Based on the supply voltage of 1.71V~1.98V, improved reliabilbridge drivery can be ensured.H bridge circuit is put into place in the way of Surface Mount.Motor driver H bridge is possible for -40°C~125°C TJ to operate normally at motor driver H bridges operating temperature.There are lots of uses for H bridge motor driver, including General Purpose.Full bridge also has a number of specific characteristics, including Diode Emulation, Status Flag.A maximum current is reached by output when H-bridge reaches 55A.
