ZF Electronics VN101503

Manufacturer No:

VN101503

Manufacturer:

ZF Electronics

Package:

Slotted Body

Description:

Hall Effect Sensor Wire Leads Digital Ferrous Vane -40°C~85°C TA 4.5V~24V Slotted Body

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

VN101503 information

ZF Electronics VN101503 technical specifications, attributes, parameters and parts with similar specifications to ZF Electronics VN101503.

Type
Parameter

Factory Lead Time
18 Weeks

Package / Case
Slotted Body

Actuator Material
Ferrous Vane

Operating Temperature
-40°C~85°C TA

Published
2010

Part Status
Active

Moisture Sensitivity Level (MSL)
1 (Unlimited)

Type
Hall Effect Sensor

Voltage - Supply
4.5V~24V

Termination Style
Wire Leads

Output Type
Digital

RoHS Status
RoHS Compliant

Download datasheets and manufacturer documentation for ZF Electronics VN101503.

Datasheets:

zfelectronics-vn101503-datasheets-7601.pdf

zf-vn101503-datasheets-2119.pdf

VN101503 Overview

A magnetic position sensor module is packaged in a Slotted Body package.

VN101503 Features

Package / Case: Slotted Body
Operating Temperature: -40°C~85°C TA
Supply Voltage: 4.5V~24V

VN101503 Applications

There are a lot of ZF Electronics
VN101503 Magnetic Position Sensors Modules applications.

Clutch/brake position sensor
Lighting actuation slave sensor
Wiper home/end position sensor
End of travel and index sensors
Industrial controls
White goods
Position and limit sensing
RPM measurement
Flow metering
Commutation of brushless DC motors
