ST VIPER15LN
Manufacturer No:
VIPER15LN
Manufacturer:
Package:
8-DIP (0.300, 7.62mm), 7 Leads
Description:
7 Terminations 8.5V~23.5V 7 Pin VIPER15 AC to DC power converter VIPer? plus Series 1 Outputs 136kHz
Quantity:
Delivery:
Payment:
In Stock :Available
Price not displayed? Please send an RFQ, and we will respond immediately.
VIPER15LN information
ST VIPER15LN technical specifications, attributes, parameters and parts with similar specifications to ST VIPER15LN.
- Type
- Parameter
- Mount
- Through Hole
- Mounting Type
- Through Hole
- Package / Case
- 8-DIP (0.300, 7.62mm), 7 Leads
- Number of Pins
- 7
- Operating Temperature
- -40°C~150°C TJ
- Packaging
- Tube
- Series
- VIPer? plus
- JESD-609 Code
- e3
- Part Status
- Obsolete
- Moisture Sensitivity Level (MSL)
- 1 (Unlimited)
- Number of Terminations
- 7
- ECCN Code
- EAR99
- Terminal Finish
- Matte Tin (Sn) - annealed
- Power (Watts)
- 10W
- Subcategory
- Switching Regulator or Controllers
- Max Power Dissipation
- 12W
- Terminal Position
- DUAL
- Number of Functions
- 1
- Terminal Pitch
- 2.54mm
- Base Part Number
- VIPER15
- Pin Count
- 7
- Number of Outputs
- 1
- Input Voltage-Nom
- 14V
- Analog IC - Other Type
- SWITCHING CONTROLLER
- Nominal Supply Current
- 2.5mA
- Voltage - Supply (Vcc/Vdd)
- 8.5V~23.5V
- Output Power
- 12W
- Input Voltage (Min)
- 8.5V
- Topology
- Flyback
- Control Mode
- CURRENT-MODE
- Frequency - Switching
- 136kHz
- Input Voltage (Max)
- 23.5V
- Control Technique
- PULSE WIDTH MODULATION
- Switcher Configuration
- SINGLE
- Internal Switch(s)
- Yes
- Fault Protection
- Current Limiting, Over Temperature, Over Voltage
- Output Isolation
- Isolated
- Voltage - Breakdown
- 800V
- Voltage - Start Up
- 14V
- Height
- 3.3mm
- Length
- 9.27mm
- Radiation Hardening
- No
- RoHS Status
- RoHS Compliant
- Lead Free
- Lead Free
Download datasheets and manufacturer documentation for ST VIPER15LN.
Datasheets:
VIPER15LN Overview
An embedded ac to dc converter is included in 8-DIP (0.300, 7.62mm), 7 Leads package.Tube case is available for the ac dc converter.Through Hole mounts this AC/DC converter.The ac dc converter needs to be operated at -40°C~150°C TJ °C in order to perform.The AC DC converter utilizes a type SWITCHING CONTROLLER analog IC.There is 136kHz switching frequency.Supply voltage (Vcc/Vdd) does not need to exceed 8.5V~23.5V .As a result, it has a total of 7 terminations.In this ac/dc converter, there are 7 pins.There are 7 pins in total.The ac dc converters are suitable for mounting by Through Hole .This AC to DC converter belongs to the VIPer? plus family of manufacturers.If you select the VIPER15 family, you will be able to search similar acdc converters.A total of 1 outputs are available for processing.The ac to dc conversions can be found in Switching Regulator or Controllers .Unique techniques can be used to ensure input voltage at the maximum value of 23.5V .The output power of a coverter is assumed to be 12W .
VIPER15LN Features
Packaged with 8-DIP (0.300, 7.62mm), 7 Leads
Switching Frequency at 136kHz
With 7 pins
VIPER15LN Applications
There are a lot of STMicroelectronics
VIPER15LN AC DC Converters applications.
- Linear Adapter Replacements
- Chargers for cell/cordless phones
- PDAs
- MP3
- Portable audio
- Adapters
- Networking
- Battery Chargers
- Power Adaptors
- Standby Power Supplies
