NICHICON UPW1J680MPD1TD
NICHICON UPW1J680MPD1TD

NICHICON UPW1J680MPD1TD

Manufacturer No:

UPW1J680MPD1TD

Manufacturer:

NICHICON

Package:

Radial, Can

Description:

UPW 68?F Capacitor ±20% Cut Tape (CT) Through Hole 263.2mA 0.315Dia 8.00mm -55°C~105°C Polar 3.5mm Radial, Can

Delivery:

DHL
DHL
DHL
DHL

Payment:

DHL
DHL
DHL
DHL
DHL
DHL

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

UPW1J680MPD1TD information

NICHICON UPW1J680MPD1TD technical specifications, attributes, parameters and parts with similar specifications to NICHICON UPW1J680MPD1TD.

  • Type
  • Parameter
  • Factory Lead Time
  • 19 Weeks
  • Mount
  • Through Hole
  • Mounting Type
  • Through Hole
  • Package / Case
  • Radial, Can
  • Terminal Shape
  • WIRE
  • Dielectric Material
  • Aluminium
  • Operating Temperature
  • -55°C~105°C
  • Packaging
  • Cut Tape (CT)
  • Series
  • UPW
  • Published
  • 2009
  • Size / Dimension
  • 0.315Dia 8.00mm
  • Tolerance
  • ±20%
  • JESD-609 Code
  • e3
  • Pbfree Code
  • yes
  • Part Status
  • Active
  • Moisture Sensitivity Level (MSL)
  • 1 (Unlimited)
  • Number of Terminations
  • 2
  • Termination
  • Radial
  • ECCN Code
  • EAR99
  • Terminal Finish
  • Matte Tin (Sn)
  • Applications
  • General Purpose
  • HTS Code
  • 8532.22.00
  • Capacitance
  • 68?F
  • Voltage - Rated DC
  • 63V
  • Lead Pitch
  • 3.5mm
  • Capacitor Type
  • ALUMINUM ELECTROLYTIC CAPACITOR
  • ESR (Equivalent Series Resistance)
  • 684mOhm
  • Lead Spacing
  • 0.138 3.50mm
  • Lifetime @ Temp
  • 3000 Hrs @ 105°C
  • Leakage Current
  • 0.12852mA
  • Ripple Current
  • 263.2mA
  • Polarization
  • Polar
  • Life (Hours)
  • 3000 hours
  • Tan Delta
  • 0.09
  • Impedance
  • 342mOhm
  • Ripple Current @ Low Frequency
  • 263.25mA @ 120Hz
  • Ripple Current @ High Frequency
  • 405mA @ 100kHz
  • Diameter
  • 8mm
  • Height
  • 11.5mm
  • Height Seated (Max)
  • 0.512 13.00mm
  • REACH SVHC
  • No SVHC
  • RoHS Status
  • RoHS Compliant
  • Lead Free
  • Lead Free

Download datasheets and manufacturer documentation for NICHICON UPW1J680MPD1TD.

Datasheets:

UPW1J680MPD1TD Overview


In terms of ripple current, it is 405mA @ 100kHz at full charge.In order for 684mOhm to perform its full function, the ESR (Equivalent Series Resistance) needs to be provided.When the charge is lowest, the ripple current is 263.25mA @ 120Hz.Sitting height (Max) should not exceed 0.512 13.00mm.Voltage - Rated DC of 63V is required to operate this capacitor.It is recommended to maintain the operating temperature at -55°C~105°C in order to maximize efficiency.

UPW1J680MPD1TD Features


the ripple current is 405mA @ 100kHz.
the ripple current is 263.25mA @ 120Hz.
voltage - Rated DC of 63V
an operating temperature of -55°C~105°C


UPW1J680MPD1TD Applications


There are a lot of Nichicon
UPW1J680MPD1TD applications of aluminum electrolytic capacitors.


  • Power supplies
  • Computer motherboards
  • Uninterruptible power supplies
  • Frequency converters
  • Computer
  • Telecommunication
  • Industrial systems
  • Smoothing and filtering applications
  • Standard and switched mode power supplies
  • Energy storage in pulse systems
