TI UC2854ADWTRG4

Manufacturer No:

UC2854ADWTRG4

Manufacturer:

Package:

SOIC

Description:

1.27mm PMIC 16 Pin 200kHz SOIC

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

UC2854ADWTRG4 information

TI UC2854ADWTRG4 technical specifications, attributes, parameters and parts with similar specifications to TI UC2854ADWTRG4.

Type
Parameter

Package / Case
SOIC

Surface Mount
YES

Number of Pins
16

Weight
473.692182mg

Packaging
Tape & Reel (TR)

JESD-609 Code
e4

Pbfree Code
no

Moisture Sensitivity Level (MSL)
2 (1 Year)

Number of Terminations
16

ECCN Code
EAR99

Terminal Finish
Nickel/Palladium/Gold (Ni/Pd/Au)

Max Operating Temperature
85°C

Min Operating Temperature
-40°C

HTS Code
8542.39.00.01

Subcategory
Switching Regulator or Controllers

Technology
BIPOLAR

Terminal Position
DUAL

Terminal Form
GULL WING

Peak Reflow Temperature (Cel)
260

Number of Functions
1

Terminal Pitch
1.27mm

Frequency
200kHz

Pin Count
16

Input Voltage-Nom
18V

Max Supply Voltage
20V

Min Supply Voltage
10V

Analog IC - Other Type
POWER FACTOR CONTROLLER

Control Mode
CURRENT-MODE

Output Current-Max
1.5A

Frequency - Switching
115kHz

Control Technique
PULSE WIDTH MODULATION

Switcher Configuration
BOOST

Length
10.3mm

Height Seated (Max)
2.65mm

Width
7.5mm

Radiation Hardening
No

RoHS Status
RoHS Compliant

Lead Free
Contains Lead

Download datasheets and manufacturer documentation for TI UC2854ADWTRG4.

UC2854ADWTRG4 Overview

Packaged in a SOIC format.A Tape & Reel (TR)-package is used.In addition to POWER FACTOR CONTROLLER, the part has other types of ICs.The gadget has several 16 terminals.Pin number 16 remains unchanged.There is a switching frequency of 115kHz.16 pins are arranged in a sum.It's like a subclass of Switching Regulator or Controllers.When the frequency is 200kHz, it is still able to maintain good accuracy.As far as output current is concerned, it works in 1.5AOperating it should result in a warmer temperature than -40°C.85°C is the maximum operating temperature at this point.20V is the only voltage that it can work with.A 10V-volt supply voltage is the only one that works with it.
