VISHAY TR3E106M050C0300

Manufacturer No:

TR3E106M050C0300

Manufacturer:

VISHAY

Package:

7343-43

Description:

10?F 20% 125°C-Max -55°C-Min 300mOhm Polar Tantalum Cut Tape 7343-43

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

TR3E106M050C0300 information

VISHAY TR3E106M050C0300 technical specifications, attributes, parameters and parts with similar specifications to VISHAY TR3E106M050C0300.

Type
Parameter

Mount
Surface Mount

Package / Case
7343-43

Number of Pins
2

Dielectric Material
Tantalum

Weight
670.01263mg

Packaging
Cut Tape

Tolerance
20%

Termination
SMD/SMT

Max Operating Temperature
125°C

Min Operating Temperature
-55°C

Voltage - Rated
50V

Capacitance
10?F

Voltage - Rated DC
50V

Depth
4.3mm

Case Code (Metric)
7343

Case Code (Imperial)
2917

ESR (Equivalent Series Resistance)
300mOhm

Polarity
Polar

Voltage
50V

Ripple Current
740mA

Dissipation Factor
6 %

Current - Leakage
5?A

Height
4mm

Length
7.3mm

REACH SVHC
Unknown

Radiation Hardening
No

RoHS Status
RoHS Compliant

Lead Free
Lead Free

Download datasheets and manufacturer documentation for VISHAY TR3E106M050C0300.

RohsStatement:

vishaydale-imc0402rk47nj-rohsstatement-4552.pdf

datasheets:

vishay-tr3b106k025c1100-datasheets-3909.pdf

TR3E106M050C0300 Overview

It is set to 740mA for the ripple current of the capacitor.In an electronic circuit consisting of a resistor and an ideal (perfect) capacitor, equivalent series resistance (ESR), or internal resistance, is the loss of useful energy.Whenever AC is applied through a capacitor, the dissipation factor is 6 %.

TR3E106M050C0300 Features

740mA is the ripple current of the capacitor
the dissipation factor is 6 %

TR3E106M050C0300 Applications

There are a lot of Vishay
TR3E106M050C0300 applications of tantalum capacitors.

Telecom infrastructure
Consumer
Computer
General purpose
General low power DC/DC and LDO
Automotive ECU
ABS
Airbag systems
Avionics,
Industrial control units
