VISHAY TMCMB1D685MTRF
Manufacturer No:
TMCMB1D685MTRF
Manufacturer:
Package:
Description:
6.8?F 20% 125°C-Max -55°C-Min 2.2Ohm
Quantity:
Delivery:




Payment:






In Stock :Available
Price not displayed? Please send an RFQ, and we will respond immediately.
TMCMB1D685MTRF information
VISHAY TMCMB1D685MTRF technical specifications, attributes, parameters and parts with similar specifications to VISHAY TMCMB1D685MTRF.
- Type
- Parameter
- Weight
- 65.005457mg
- Tolerance
- 20%
- Termination
- SMD/SMT
- Max Operating Temperature
- 125°C
- Min Operating Temperature
- -55°C
- Voltage - Rated
- 20V
- Capacitance
- 6.8?F
- Case Code (Metric)
- 3528
- Case Code (Imperial)
- 1311
- ESR (Equivalent Series Resistance)
- 2.2Ohm
- Ripple Current
- 209mA
- Dissipation Factor
- 6 %
- Current - Leakage
- 1.4?A
- Height
- 2.1mm
- Length
- 3.5mm
- Width
- 2.8mm
- RoHS Status
- RoHS Compliant
Download datasheets and manufacturer documentation for VISHAY TMCMB1D685MTRF.
RohsStatement:
datasheets:
TMCMB1D685MTRF Overview
It is set to 209mA for the ripple current of the capacitor.In an electronic circuit consisting of a resistor and an ideal (perfect) capacitor, equivalent series resistance (ESR), or internal resistance, is the loss of useful energy.Whenever AC is applied through a capacitor, the dissipation factor is 6 %.
TMCMB1D685MTRF Features
209mA is the ripple current of the capacitor
the dissipation factor is 6 %
TMCMB1D685MTRF Applications
There are a lot of Vishay
TMCMB1D685MTRF applications of tantalum capacitors.
- Telecom infrastructure
- Consumer
- Computer
- General purpose
- General low power DC/DC and LDO
- Automotive ECU
- ABS
- Airbag systems
- Avionics,
- Industrial control units
