Trinamic Motion Control GmbH TMC603A-LA

Manufacturer No:

TMC603A-LA

Manufacturer:

Trinamic Motion Control GmbH

Package:

52-VFQFN Exposed Pad

Description:

Motor Drivers 1

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

TMC603A-LA information

Trinamic Motion Control GmbH TMC603A-LA technical specifications, attributes, parameters and parts with similar specifications to Trinamic Motion Control GmbH TMC603A-LA.

Type
Parameter

Factory Lead Time
6 Weeks

Mount
Surface Mount

Mounting Type
Surface Mount

Package / Case
52-VFQFN Exposed Pad

Operating Temperature
-40°C~125°C TA

Packaging
Tray

Published
2010

Part Status
Active

Moisture Sensitivity Level (MSL)
3 (168 Hours)

Applications
General Purpose

Technology
Power MOSFET

Voltage - Supply
3.3V~5V

Function
Controller - Commutation, Direction Management

Number of Outputs
3

Number of Channels
1

Interface
PWM

Output Configuration
Pre-Driver - Half Bridge (3)

Voltage - Load
12V~50V

Motor Type - AC, DC
Brushless DC (BLDC)

RoHS Status
RoHS Compliant

Download datasheets and manufacturer documentation for Trinamic Motion Control GmbH TMC603A-LA.

Datasheets:

trinamic-tmc603ala-datasheets-6400.pdf

TMC603A-LA Overview

This package is designed to work with [0].This part is packaged with a case of [0].Mounting the part by Surface Mountis recommended.As a result, it is appropriate for the component connected to General Purpose.The device is capable of supplying a voltage of 3.3V~5V volts.A range of -40°C~125°C TAis available for operating temperature.Motors can be classified as Brushless DC (BLDC).Voltage can be applied at a rate of 12V~50V volts to the load.In terms of mounting, it is recommended that it be mounted in Surface Mount.Currently, there are 3 outputs available.On this device, there are 1channels.

TMC603A-LA Features

Applications : General Purpose
Load voltage across the chip 12V~50V
designed with 3 outputs

TMC603A-LA Applications

There are a lot of Trinamic Motion Control GmbH
TMC603A-LA motor drivers applications.

Smart lighting applications
Automotive applications
Dome
Dash
Footwell lighting
Indicator
Telltale lights
Infotainment backlighting
Tail lights
Turn signals
