NXP TDA8933BTW/N2,512

Manufacturer No:

TDA8933BTW/N2,512

Manufacturer:

NXP

Package:

32-TSSOP (0.240, 6.10mm Width) Exposed Pad

Description:

20 kHz kHz Audio Amplifiers 6.1mm mm 18V V 32-TSSOP (0.240, 6.10mm Width) Exposed Pad

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

TDA8933BTW/N2,512 information

NXP TDA8933BTW/N2,512 technical specifications, attributes, parameters and parts with similar specifications to NXP TDA8933BTW/N2,512.

Type
Parameter

Mounting Type
Surface Mount

Package / Case
32-TSSOP (0.240, 6.10mm Width) Exposed Pad

Surface Mount
YES

Operating Temperature
-40°C~85°C TA

Packaging
Tube

Published
2008

Feature
Depop, Differential Inputs, Mute, Short-Circuit and Thermal Protection

Part Status
Obsolete

Moisture Sensitivity Level (MSL)
3 (168 Hours)

Number of Terminations
32

ECCN Code
EAR99

Type
Class D

HTS Code
8542.33.00.01

Subcategory
Audio/Video Amplifiers

Voltage - Supply
10V~36V ±5V~18V

Terminal Position
DUAL

Terminal Form
GULL WING

Number of Functions
1

Terminal Pitch
0.65mm

Reach Compliance Code
unknown

Base Part Number
TDA8933

Pin Count
32

JESD-30 Code
R-PDSO-G32

Qualification Status
Not Qualified

Supply Voltage-Max (Vsup)
18V

Power Supplies
25V

Supply Voltage-Min (Vsup)
5V

Number of Channels
2

Supply Current-Max
50mA

Output Power
20.6W

Bandwidth
20 kHz

Gain
36 dB

Max Output Power x Channels @ Load
20.6W x 1 @ 16 ?; 10.3W x 2 @ 8 ?

Harmonic Distortion
10%

Length
11mm

Height Seated (Max)
1.1mm

Width
6.1mm

RoHS Status
RoHS Compliant

Download datasheets and manufacturer documentation for NXP TDA8933BTW/N2,512.

Datasheets:

nxpusainc-tda8933btwn2512-datasheets-5405.pdf

TDA8933BTW/N2,512 Overview

This package is embedded in 32-TSSOP (0.240, 6.10mm Width) Exposed Pad .This device is packaged in the way of Tube .32 terminations occur when a transmission line is terminated by a device with the same characteristic impedance as the transmission line.Amp parts uses 1-Channel (Mono) or 2-Channel (Stereo) as the output.Class D is the type of this electrical device.Amp parts is mounted in the way of Surface Mount .There is 10V~36V ±5V~18V supply voltage for this electrical device.Amp parts is equipped wAmp partsh 2 channels.When operating, it is possible to ensure Depop, Differential Inputs, Mute, Short-Circuit and Thermal Protection .Ideally, the operating temperature should not exceed -40°C~85°C TA .The device is equipped with 32 pins.Audio/Video Amplifiers incorporates this part.This item belongs to the family of TDA8933 .Amp parts is recommended that the supply voltage (Vsup) be maintained above 5V for normal operation.18V represents the maximal supply voltage (Vsup).The device is powered by a voltage of 25V .A maximum supply current of 50mA can be reached.
