Manufacturer No:

SX1503I091TRT

Manufacturer:

SEMTECH

Package:

28-UFQFN Exposed Pad

Description:

28 Termination 0.4mm I/O Expander SX150 20 Pin 3.3V 28-UFQFN Exposed Pad

Delivery:

DHL
DHL
DHL
DHL

Payment:

DHL
DHL
DHL
DHL
DHL
DHL

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

SX1503I091TRT information

SEMTECH SX1503I091TRT technical specifications, attributes, parameters and parts with similar specifications to SEMTECH SX1503I091TRT.

  • Type
  • Parameter
  • Factory Lead Time
  • 16 Weeks
  • Mount
  • Surface Mount
  • Mounting Type
  • Surface Mount
  • Package / Case
  • 28-UFQFN Exposed Pad
  • Number of Pins
  • 20
  • Operating Temperature
  • -40°C~85°C
  • Packaging
  • Tape & Reel (TR)
  • Published
  • 2012
  • JESD-609 Code
  • e3
  • Feature
  • POR
  • Part Status
  • Active
  • Moisture Sensitivity Level (MSL)
  • 1 (Unlimited)
  • Number of Terminations
  • 28
  • Terminal Finish
  • MATTE TIN
  • HTS Code
  • 8542.39.00.01
  • Voltage - Supply
  • 1.2V~5.5V
  • Terminal Position
  • QUAD
  • Terminal Form
  • NO LEAD
  • Peak Reflow Temperature (Cel)
  • NOT SPECIFIED
  • Number of Functions
  • 1
  • Supply Voltage
  • 3.3V
  • Terminal Pitch
  • 0.4mm
  • Reach Compliance Code
  • unknown
  • Time@Peak Reflow Temperature-Max (s)
  • NOT SPECIFIED
  • Pin Count
  • 28
  • JESD-30 Code
  • S-PQCC-N28
  • Qualification Status
  • Not Qualified
  • Output Type
  • Push-Pull
  • Operating Supply Voltage
  • 5.5V
  • Interface
  • I2C
  • Number of I/O
  • 16
  • Nominal Supply Current
  • 1?A
  • Output Current
  • 24mA
  • Clock Frequency
  • 400kHz
  • Telecom IC Type
  • TELECOM CIRCUIT
  • Max Junction Temperature (Tj)
  • 125°C
  • Ambient Temperature Range High
  • 85°C
  • Interrupt Output
  • Yes
  • Current - Output Source/Sink
  • 8mA 24mA
  • Height
  • 600?m
  • Length
  • 4mm
  • Width
  • 4mm
  • RoHS Status
  • RoHS Compliant
  • Lead Free
  • Lead Free

Download datasheets and manufacturer documentation for SEMTECH SX1503I091TRT.

Datasheets:

PCN Packaging:

SX1503I091TRT Overview


Using 16 I/Os, it is programmed.28-UFQFN Exposed Pad comes with the device enclosed in the packaging.The case comes in the Tape & Reel (TR) style.Votage is provided within 1.2V~5.5V.The mounting type recommended for it is Surface Mount.Devices work when the operating temperature ranges -40°C~85°C.The performance of the output frequency is determined by 400kHz.In terms of termination, it is characterized by 28 termination as a whole.In total, the part has 28 pins.There is voltage at 3.3V provided by the device.In order to run NOT SPECIFIED, the peak reflow temperature of this part is used.On the basis of the SX150 family, you can look for related parts.POR can also be founded with this device.It has 20 pins.Mounting can be done using Surface Mount.In the presence of a voltage of 5.5V, the chip conducts.It is possible to supply the device with a maximum current of 24mA.
