ST STTA2512P
ST STTA2512P

ST STTA2512P

Manufacturer No:

STTA2512P

Manufacturer:

ST

Package:

SOD-93-2

Description:

Standard Rectifier Diode 2 Independent Fast Recovery =< 500ns, > 200mA (Io) 150°C Max 25A 1.2kV-DC 1-Element SOD-93-2 Through Hole

Delivery:

DHL
DHL
DHL
DHL

Payment:

DHL
DHL
DHL
DHL
DHL
DHL

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

STTA2512P information

ST STTA2512P technical specifications, attributes, parameters and parts with similar specifications to ST STTA2512P.

  • Type
  • Parameter
  • Mount
  • Radial, Through Hole
  • Mounting Type
  • Through Hole
  • Package / Case
  • SOD-93-2
  • Diode Element Material
  • SILICON
  • Packaging
  • Tube
  • Series
  • TURBOSWITCH?
  • JESD-609 Code
  • e3
  • Part Status
  • Obsolete
  • Moisture Sensitivity Level (MSL)
  • 1 (Unlimited)
  • Number of Terminations
  • 2
  • ECCN Code
  • EAR99
  • Terminal Finish
  • Matte Tin (Sn)
  • Max Operating Temperature
  • 150°C
  • Min Operating Temperature
  • -65°C
  • Additional Feature
  • FREE WHEELING DIODE, LOW POWER LOSS
  • HTS Code
  • 8541.10.00.80
  • Subcategory
  • Rectifier Diodes
  • Voltage - Rated DC
  • 1.2kV
  • Peak Reflow Temperature (Cel)
  • NOT SPECIFIED
  • Reach Compliance Code
  • not_compliant
  • Current Rating
  • 25A
  • Time@Peak Reflow Temperature-Max (s)
  • NOT SPECIFIED
  • Base Part Number
  • STTA251
  • Pin Count
  • 2
  • JESD-30 Code
  • R-PSFM-T2
  • Qualification Status
  • Not Qualified
  • Number of Elements
  • 1
  • Element Configuration
  • Single
  • Speed
  • Fast Recovery =< 500ns, > 200mA (Io)
  • Diode Type
  • Standard
  • Current - Reverse Leakage @ Vr
  • 150?A @ 480V
  • Power Dissipation
  • 62.5W
  • Output Current
  • 25A
  • Voltage - Forward (Vf) (Max) @ If
  • 2.1V @ 25A
  • Case Connection
  • CATHODE
  • Operating Temperature - Junction
  • 150°C Max
  • Max Surge Current
  • 210A
  • Application
  • HIGH VOLTAGE ULTRA FAST SOFT RECOVERY
  • Voltage - DC Reverse (Vr) (Max)
  • 1200V
  • Max Reverse Voltage (DC)
  • 1.2kV
  • Average Rectified Current
  • 25A
  • Number of Phases
  • 1
  • Reverse Recovery Time
  • 110 ns
  • Peak Reverse Current
  • 150?A
  • Reverse Voltage
  • 1.2kV
  • Diode Configuration
  • 2 Independent
  • Recovery Time
  • 110 ns

Download datasheets and manufacturer documentation for ST STTA2512P.

Datasheets:

STTA2512P Overview


Maintaining a surge current under 210A and not letting it exceed it is the key to preventing it.This part can draw 25A current.A reverse voltage peak of 150?A is applied to devices like this one.Electronics and electrical devices create heat as a byproduct of their primary action.

STTA2512P Features


a peak voltage of 150?A
a reverse voltage peak of 150?A


STTA2512P Applications


There are a lot of STMicroelectronics
STTA2512P applications of rectifier diode array.


  • Rectifier for drives applications
  • Crowbar applications
  • Rectifiers for UBS
  • Battery chargers
  • Rectifiers in switch mode power supplies (SMPS)
  • Free wheeling diode in low voltage converters
  • General Rectification
