ST STP4CMPQTR

Manufacturer No:

STP4CMPQTR

Manufacturer:

Package:

20-UFQFN

Description:

3/5V PMIC STP4C 20 Pin 3.3V 20-UFQFN

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

STP4CMPQTR information

ST STP4CMPQTR technical specifications, attributes, parameters and parts with similar specifications to ST STP4CMPQTR.

Type
Parameter

Lifecycle Status
ACTIVE (Last Updated: 7 months ago)

Factory Lead Time
10 Weeks

Mount
Surface Mount

Mounting Type
Surface Mount

Package / Case
20-UFQFN

Number of Pins
20

Operating Temperature
-40°C~85°C TA

Packaging
Tape & Reel (TR)

JESD-609 Code
e4

Part Status
Active

Moisture Sensitivity Level (MSL)
1 (Unlimited)

Number of Terminations
20

ECCN Code
EAR99

Type
DC DC Regulator

Terminal Finish
Nickel/Palladium/Gold (Ni/Pd/Au)

Applications
Backlight

Subcategory
Display Drivers

Terminal Position
QUAD

Peak Reflow Temperature (Cel)
260

Number of Functions
1

Supply Voltage
3.3V

Base Part Number
STP4C

Pin Count
20

Number of Outputs
4

Max Supply Voltage
5.5V

Min Supply Voltage
2.7V

Nominal Supply Current
17.2mA

Voltage - Output
3.8V

Topology
Switched Capacitor (Charge Pump)

Current - Output / Channel
30mA

Internal Switch(s)
Yes

Low Level Output Current
32.1mA

Dimming
PWM

Number of Segments
4

Voltage - Supply (Min)
2.7V

Multiplexed Display Capability
NO

Length
3.2mm

Height Seated (Max)
0.55mm

Width
1.8mm

Radiation Hardening
No

RoHS Status
RoHS Compliant

Lead Free
Lead Free

Download datasheets and manufacturer documentation for ST STP4CMPQTR.

Datasheets:

stmicroelectronics-stp4cmpqtr-datasheets-8000.pdf

STP4CMPQTR Overview

There is a 20-UFQFN package on the board that is used to save space. The LED driver's design uses 4 outputs.Mounting is done according to the Surface Mount method.With high efficiency and reliable performance, it emerges as a DC DC Regulator.When the temperature is -40°C~85°C TA, it can work normally.There are significant benefits for Backlight.It is designed to work with 20 terminations.Its configuration is based on 20 pins.It is likely that undetermined failures will occur if the voltage supply is less than 2.7V.4 segments exist.The mount is on its way to Surface Mount.The LED driver can be found under the base part number STP4C.An acceptable maximum value for the supply voltage is 5.5V.The voltage output by it is 3.8V.20 pins are included in it.As a result of its characteristics, it is also classified as Display Drivers.With a minimal supply voltage of 2.7V, it reaches the highest efficiency levels.

STP4CMPQTR Features

Available in the 20-UFQFN package
Operating temperature of -40°C~85°C TA
Supply voltage of 3.3V

STP4CMPQTR Applications

There are a lot of STMicroelectronics
STP4CMPQTR LED Driver ICs applications.

Refrigeration lighting
Portable lighting
Gallery lighting
Museum lighting
High-end retail lighting
Medical surgery lighting
Replacement lamps
Panel lighting
Down lights
Linear fluorescent
