ST STM32L476JGY6TR
ST STM32L476JGY6TR

ST STM32L476JGY6TR

Manufacturer No:

STM32L476JGY6TR

Manufacturer:

ST

Package:

72-UFBGA, WLCSP

Description:

1MB 1M x 8 FLASH ARM® Cortex®-M4 32-Bit Microcontroller STM32L4 Series STM32L476 72 Pin 80MHz 1.8V 72-UFBGA, WLCSP

Delivery:

DHL
DHL
DHL
DHL

Payment:

DHL
DHL
DHL
DHL
DHL
DHL
DHL

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

STM32L476JGY6TR information

ST STM32L476JGY6TR technical specifications, attributes, parameters and parts with similar specifications to ST STM32L476JGY6TR.

  • Type
  • Parameter
  • Factory Lead Time
  • 12 Weeks
  • Mounting Type
  • Surface Mount
  • Package / Case
  • 72-UFBGA, WLCSP
  • Surface Mount
  • YES
  • Number of Pins
  • 72
  • Operating Temperature
  • -40°C~85°C TA
  • Packaging
  • Tape & Reel (TR)
  • Series
  • STM32L4
  • Part Status
  • Active
  • Moisture Sensitivity Level (MSL)
  • 1 (Unlimited)
  • Number of Terminations
  • 72
  • ECCN Code
  • 3A991.A.2
  • HTS Code
  • 8542.31.00.01
  • Technology
  • CMOS
  • Terminal Position
  • BOTTOM
  • Terminal Form
  • BALL
  • Supply Voltage
  • 1.8V
  • Terminal Pitch
  • 0.4mm
  • Frequency
  • 80MHz
  • Base Part Number
  • STM32L476
  • Supply Voltage-Max (Vsup)
  • 3.6V
  • Supply Voltage-Min (Vsup)
  • 1.71V
  • Memory Size
  • 1MB
  • Oscillator Type
  • Internal
  • RAM Size
  • 128K x 8
  • Voltage - Supply (Vcc/Vdd)
  • 1.71V~3.6V
  • uPs/uCs/Peripheral ICs Type
  • MICROCONTROLLER, RISC
  • Core Processor
  • ARM® Cortex®-M4
  • Peripherals
  • Brown-out Detect/Reset, DMA, LCD, PWM, WDT
  • Program Memory Type
  • FLASH
  • Core Size
  • 32-Bit
  • Program Memory Size
  • 1MB 1M x 8
  • Connectivity
  • CANbus, I2C, IrDA, LINbus, MMC/SD, QSPI, SAI, SPI, SWPMI, UART/USART, USB OTG
  • Bit Size
  • 32
  • Data Converter
  • A/D 16x12b; D/A 2x12b
  • Has ADC
  • YES
  • DMA Channels
  • YES
  • PWM Channels
  • YES
  • DAC Channels
  • YES
  • Address Bus Width
  • 2
  • On Chip Program ROM Width
  • 8
  • CPU Family
  • CORTEX-M4
  • Boundary Scan
  • YES
  • Low Power Mode
  • YES
  • Format
  • FLOATING-POINT
  • Integrated Cache
  • NO
  • RAM (words)
  • 128000

Download datasheets and manufacturer documentation for ST STM32L476JGY6TR.

Datasheets:

STM32L476JGY6TR Description


The STM32L476xx devices are ultra-low-power microcontrollers built on the powerful 32-bit RISC Arm? Cortex?-M4 core that operates at up to 80 MHz. A floating point unit (FPU) single precision is a characteristic of the Cortex-M4 core that supports all Arm? single-precision data-processing instructions and data formats. Additionally, it incorporates a memory protection unit (MPU) that improves program security together with the whole range of DSP instructions.

The STM32L476xx devices include a wide range of enhanced I/Os and peripherals connected to two APB buses, two AHB buses, and a 32-bit multi-AHB bus matrix. They also include high-speed memories (Flash memory up to 1 Mbyte and up to 128 Kbyte of SRAM), a flexible external memory controller (FSMC) for static memories (for devices with packages of 100 pins and more), a Quad SPI flash memories interface (available on all packages.



STM32L476JGY6TR Features


  • 1.71 V to 3.6 V power supply

  • -40 °C to 85/105/125 °C temperature range

  • 300 nA in VBAT mode: supply for RTC and 32x32-bit backup registers

  • 30 nA Shutdown mode (5 wakeup pins)

  • 120 nA Standby mode (5 wakeup pins)

  • 420 nA Standby mode with RTC

  • 1.1 μA Stop 2 mode, 1.4 μA with RTC

  • 100 μA/MHz run mode (LDO Mode)

  • 39 μA/MHz run mode (@3.3 V SMPS Mode)

  • Batch acquisition mode (BAM)

  • 4 μs wakeup from Stop mode

  • Brown out reset (BOR)

  • Interconnect matrix



STM32L476JGY6TR Applications


  • Power Management

  • Consumer Electronics

  • Portable Devices

  • Industrial
