ST STM32F429AGH6TR

Manufacturer No:

STM32F429AGH6TR

Manufacturer:

Package:

UFBGA-169

Description:

Description: High-performance advanced line, Arm Cortex-M4 core with DSP and FPU, 1 Mbyte of Flash memory, 180 MHz CPU, ART Accelerator, Chrom-ART Accelerator, FMC with SDRAM, TFT

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

STM32F429AGH6TR information

ST STM32F429AGH6TR technical specifications, attributes, parameters and parts with similar specifications to ST STM32F429AGH6TR.

Type
Parameter

RoHS Status
RoHS Compliant

Part Life Cycle Code
Active

Ihs Manufacturer
STMICROELECTRONICS

Package Description
UFBGA-169

Reach Compliance Code
compliant

ECCN Code
3A991.A.2

HTS Code
8542.31.00.01

Factory Lead Time
15 Weeks

Samacsys Manufacturer
STMicroelectronics

Has ADC
YES

Address Bus Width
26

Bit Size
32

Boundary Scan
YES

CPU Family
CORTEX-M4

Clock Frequency-Max
26 MHz

DAC Channels
YES

DMA Channels
YES

External Data Bus Width
32

Format
FLOATING POINT

Integrated Cache
NO

JESD-30 Code
S-PBGA-B169

Length
7 mm

Low Power Mode
YES

Number of DMA Channels
2

Number of I/O Lines
130

Number of Serial I/Os
6

Number of Terminals
169

Number of Timers
15

On Chip Data RAM Width
8

On Chip Program ROM Width
8

Operating Temperature-Max
85 °C

Operating Temperature-Min
-40 °C

PWM Channels
YES

Package Body Material
PLASTIC/EPOXY

Package Code
VFBGA

Package Equivalence Code
BGA169,13X13,20

Package Shape
SQUARE

Package Style
GRID ARRAY, VERY THIN PROFILE, FINE PITCH

Peak Reflow Temperature (Cel)
NOT SPECIFIED

RAM (bytes)
266240

ROM (words)
1048576

ROM Programmability
FLASH

Seated Height-Max
0.6 mm

Speed
180 MHz

Supply Current-Max
100 mA

Supply Voltage-Max
3.6 V

Supply Voltage-Min
3.3 V

Download datasheets and manufacturer documentation for ST STM32F429AGH6TR.

Datasheets:

en.DM00071990.pdf

STM32F429AGH6TR Overview

The package has a 169-UFBGA shape. With 130 I/Os, it's pretty good. The Microcontroller's mounting type is Surface Mount and this IC chip has the following features. As the name implies, this Microcontroller is based on the 32-Bit core. As far as its program memory type is concerned, it is FLASH. Temperatures within -40°C~85°C TA range are measured by this Microcontroller. The STM32F4 series is comprised of this electrical component. The electronic part has a program memory size of 1MB 1M x 8. There's a ARM® Cortex®-M4 Core Processor inside. The IC chip fits into the MICROCONTROLLER, RISC uPs/uCs/Peripheral ICs category. There are 169 terminations on the IC chip. 32-bits are the size of the data that comes with MCU. A 3.3V volt supply is provided by the Microcontroller chip. In addition to that, MCU chip has YES DMA channels. It is possible to find alternatives to the base part number STM32F429 by using the part number search tool. There are a total of YES channels in the device. There are several CPUs that are embedded in the device, including the the CORTEX-M4 CPU. The clock frequency is 26MHz. It is designed with 6 serial inputs and outputs (I/Os).

STM32F429AGH6TR Features

169-UFBGA package
Mounting type of Surface Mount

STM32F429AGH6TR Applications

There are a lot of STMicroelectronics
STM32F429AGH6TR Microcontroller applications.

Robots
Radio
Television
Heater/Fan
Calculator
Kindle
Christmas lights
3D printers
Washing machine
Microwave ovens
