ONSEMI STK672-610

Manufacturer No:

STK672-610

Manufacturer:

ONSEMI

Package:

19-SSIP Formed Leads

Description:

14.4mm mm 4.5mm mm Motor Drivers 19 5V V 29.2mm mm Motion Control Electronics

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

STK672-610 information

ONSEMI STK672-610 technical specifications, attributes, parameters and parts with similar specifications to ONSEMI STK672-610.

Type
Parameter

Lifecycle Status
LIFETIME (Last Updated: 2 weeks ago)

Factory Lead Time
12 Weeks

Mount
Through Hole

Mounting Type
Through Hole

Package / Case
19-SSIP Formed Leads

Number of Pins
19

Operating Temperature
0°C~105°C TC

Packaging
Tube

Published
2008

JESD-609 Code
e2

Pbfree Code
yes

Part Status
Obsolete

Moisture Sensitivity Level (MSL)
1 (Unlimited)

Number of Terminations
19

Terminal Finish
Tin/Nickel (Sn/Ni)

Applications
General Purpose

HTS Code
8542.39.00.01

Subcategory
Motion Control Electronics

Technology
Power MOSFET

Voltage - Supply
4.75V~5.25V

Terminal Position
ZIG-ZAG

Supply Voltage
5V

Terminal Pitch
1mm

Function
Driver - Fully Integrated, Control and Power Stage

Power Supplies
524V

Supply Voltage-Min (Vsup)
4.75V

Interface
Parallel

Nominal Supply Current
9mA

Output Configuration
Half Bridge (2)

Power Dissipation
10.2W

Current - Output
3.3A

Logic Function
AND

Collector Emitter Voltage (VCEO)
42V

Max Collector Current
3A

Voltage - Load
10V~42V

Switching Frequency
45kHz

Motor Type
Stepper

Motor Type - Stepper
Unipolar

Step Resolution
1, 1/2

Height
14.4mm

Length
29.2mm

Width
4.5mm

Radiation Hardening
No

RoHS Status
RoHS Compliant

Lead Free
Lead Free

Download datasheets and manufacturer documentation for ONSEMI STK672-610.

Datasheets:

onsemiconductor-stk672610-datasheets-6323.pdf

ReachStatement:

onsemiconductor-6svp22m-reachstatement-6839.pdf

STK672-610 Overview

The package is designed with [0].The part is packaged in a 19-SSIP Formed Leads case.In general, it is recommended that the part be mounted by Through Hole.The component connected in General Purposeis compatible with it.4.75V~5.25V volts can be supplied by the device.Drivers controllers operates wDrivers controllershin a range of 0°C~105°C TCdegrees Celsius.This part has 19termination options.A voltage of 10V~42Vcan be applied to the load.This amplifier should be operated at 5V.Ideally, it should be mounted in the Through Holeposition.Maintain a current of 3.3Afor the part output.The device has 19 pins.The item belongs to the Motion Control Electronics series.The motor type can be identified as Stepper.

STK672-610 Features

Applications : General Purpose
Load voltage across the chip 10V~42V
Motor Type classified as Stepper
