ST STG4160BJR
Manufacturer No:
STG4160BJR
Manufacturer:
Package:
8-UFBGA, FCBGA
Description:
38ns, 38ns SPDT 500mOhm BOTTOM Analog Switches BREAK-BEFORE-MAKE STG4160 8 Pins 30nA 8-UFBGA, FCBGA
Quantity:
Delivery:
Payment:
In Stock :Available
Price not displayed? Please send an RFQ, and we will respond immediately.
STG4160BJR information
ST STG4160BJR technical specifications, attributes, parameters and parts with similar specifications to ST STG4160BJR.
- Type
- Parameter
- Lifecycle Status
- ACTIVE (Last Updated: 7 months ago)
- Factory Lead Time
- 24 Weeks
- Mount
- Surface Mount
- Mounting Type
- Surface Mount
- Package / Case
- 8-UFBGA, FCBGA
- Number of Pins
- 8
- Operating Temperature
- -40°C~85°C TA
- Packaging
- Tape & Reel (TR)
- JESD-609 Code
- e1
- Part Status
- Active
- Moisture Sensitivity Level (MSL)
- 1 (Unlimited)
- Number of Terminations
- 8
- ECCN Code
- EAR99
- Resistance
- 500mOhm
- Terminal Finish
- Tin/Silver/Copper (Sn/Ag/Cu)
- Subcategory
- Multiplexer or Switches
- Max Power Dissipation
- 500mW
- Technology
- CMOS
- Terminal Position
- BOTTOM
- Terminal Form
- BALL
- Number of Functions
- 1
- Terminal Pitch
- 0.5mm
- Base Part Number
- STG4160
- Pin Count
- 8
- Max Supply Voltage
- 4.8V
- Min Supply Voltage
- 1.65V
- Power Dissipation
- 500mW
- Max Supply Current
- 50nA
- Turn On Delay Time
- 38 ns
- Number of Inputs
- 1
- Supply Type
- Single
- Turn-Off Delay Time
- 38 ns
- -3db Bandwidth
- 50MHz
- On-State Resistance (Max)
- 500mOhm
- Multiplexer/Demultiplexer Circuit
- 2:1
- Current - Leakage (IS(off)) (Max)
- 30nA
- Channel Capacitance (CS(off), CD(off))
- 30pF
- Switch Circuit
- SPDT
- Switch Time (Ton, Toff) (Max)
- 38ns, 38ns
- Charge Injection
- 162pC
- Channel-to-Channel Matching (?Ron)
- 10m ?
- Crosstalk
- -67dB @ 1MHz
- Switching
- BREAK-BEFORE-MAKE
- Voltage - Supply, Single (V+)
- 1.65V~4.8V
- Radiation Hardening
- No
- RoHS Status
- RoHS Compliant
Download datasheets and manufacturer documentation for ST STG4160BJR.
STG4160BJR Overview
As the electronic part is packed in 8-UFBGA, FCBGA, international shipping is convenient. A high level of reliability can be achieved through the use of an advanced packaging method Tape & Reel (TR). The multiplexer is located in Surface Mount. 2:1 is the number of circuits in the multiplexer and demultiplexer. Operating temperature extended to -40°C~85°C TA. Total terminations are 8. It is part of the design of the 8 series that this electronic component is included. Circuits based on SPDT switching are used to construct these analog switch ics. Try searching with STG4160 to find analog multiplexer variants. An switch multiplexer with 500mOhm internal resistance has a value of 500mOhm. Datasheets for 8 pin functions are available upon request. The analogue multiplexer in this example is a typical Multiplexer or Switches. Multiplexers should not be powered above 4.8V in normal situations. The analog switch ic is of the Single supply type and is cost-effective. The lowest voltage the electronic part should receive is 1.65V. Using a single voltage supply, this switch device consumes 1.65V~4.8V volts. When the digital multiplexer is charged above 50nA, damage can occur. Operating the 1 inputs requires 1 inputs. A analog switch ics with 2 outputs is included.
STG4160BJR Features
Switch Circuit: SPDT
-3db Bandwidth: 50MHz
STG4160BJR Applications
There are a lot of STMicroelectronics
STG4160BJR Analog Switches & Multiplexers ICs applications.
- Imaging
- Ultrasound
- Audio and video switching
- Automatic test equipment
- Precision data acquisition
- Battery-powered systems
- Sample-and-hold systems
- Communication systems
- Data Acquisition Systems
- Relay Replacement
