ADI SSM3302ACPZ-R7

Manufacturer No:

SSM3302ACPZ-R7

Manufacturer:

ADI

Package:

40-WFQFN Exposed Pad, CSP

Description:

12.2mA mA 36.6W W Audio Amplifiers 40 pins 40-WFQFN Exposed Pad, CSP

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

SSM3302ACPZ-R7 information

ADI SSM3302ACPZ-R7 technical specifications, attributes, parameters and parts with similar specifications to ADI SSM3302ACPZ-R7.

Type
Parameter

Lifecycle Status
PRODUCTION (Last Updated: 2 weeks ago)

Factory Lead Time
8 Weeks

Mount
Surface Mount

Mounting Type
Surface Mount

Package / Case
40-WFQFN Exposed Pad, CSP

Number of Pins
40

Operating Temperature
-40°C~85°C TA

Packaging
Tape & Reel (TR)

JESD-609 Code
e3

Feature
Depop, Differential Inputs, Short-Circuit and Thermal Protection, Shutdown

Pbfree Code
no

Part Status
Active

Moisture Sensitivity Level (MSL)
3 (168 Hours)

Number of Terminations
40

ECCN Code
EAR99

Type
Class D

Terminal Finish
Matte Tin (Sn)

Subcategory
Audio/Video Amplifiers

Technology
DMOS

Voltage - Supply
7V~18V

Terminal Position
QUAD

Peak Reflow Temperature (Cel)
260

Number of Functions
2

Terminal Pitch
0.5mm

Base Part Number
SSM3302

Pin Count
40

Efficiency
91 %

Output Type
2-Channel (Stereo)

Number of Channels
2

Operating Supply Current
12.2mA

Nominal Supply Current
12.2mA

Output Power
10W

Common Mode Rejection Ratio
43 dB

Supply Type
Single

Power Supply Rejection Ratio (PSRR)
80dB

Gain
24 dB

Max Output Power
36.6W

Signal to Noise Ratio (SNR)
98 dB

Max Output Power x Channels @ Load
36.6W x 1 @ 2 ?; 24W x 2 @ 4 ?

Radiation Hardening
No

RoHS Status
RoHS Compliant

Lead Free
Contains Lead

Download datasheets and manufacturer documentation for ADI SSM3302ACPZ-R7.

SSM3302ACPZ-R7 Overview

In the 40-WFQFN Exposed Pad, CSP package, it is embedded.In this case, it is packaged as Tape & Reel (TR) .In addition, there are 40 terminations, which involve the termination of a transmission line with a device that matches the characteristic impedance of the line.In the configuration, 2-Channel (Stereo) is used as the output.This electrical device is classified as type Class D .As part of a signal interface in a computer or other communication device, there are 40 pins, which are pronged contacts.In this case, the electronic part is mounted in the way of Surface Mount .There is 7V~18V voltage supply to this electrical device.2 channels are available on the device.Operating with Depop, Differential Inputs, Short-Circuit and Thermal Protection, Shutdown is possible.Temperatures should not exceed -40°C~85°C TA .There are 40 pins on this device.As part of Audio/Video Amplifiers , this part is included.Amp parts belongs to the SSM3302 family.In this case, the electronic part is mounted in the way of Surface Mount .According to the manufacturer, the maximum output power of this electronic component is 36.6W kWh per hour.Amp parts is a Single supply type.

SSM3302ACPZ-R7 Features

40-WFQFN Exposed Pad, CSP package
40 pin count
SSM3302 family
36.6W kWh per hour

SSM3302ACPZ-R7 Applications

There are a lot of Analog Devices Inc.
SSM3302ACPZ-R7 audio amplifiers applications.

single/dual op amp sum and difference circuits
Integrator and differentiator circuits
Logarithmic and exponential operation circuits
Multiplication and division circuits
Precision measurement
Power control
Information processing
Weak signal detection
Signal amplification
Signal filtering
