Manufacturer No:

SSM2604CPZ-REEL7

Manufacturer:

ADI

Package:

20-VFQFN Exposed Pad, CSP

Description:

20 Termination 0.5mm CODEC SSM2604 20 Pin 3.3V 20-VFQFN Exposed Pad, CSP

Delivery:

DHL
DHL
DHL
DHL

Payment:

DHL
DHL
DHL
DHL
DHL
DHL
DHL

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

SSM2604CPZ-REEL7 information

ADI SSM2604CPZ-REEL7 technical specifications, attributes, parameters and parts with similar specifications to ADI SSM2604CPZ-REEL7.

  • Type
  • Parameter
  • Lifecycle Status
  • PRODUCTION (Last Updated: 2 weeks ago)
  • Factory Lead Time
  • 8 Weeks
  • Mount
  • Surface Mount
  • Mounting Type
  • Surface Mount
  • Package / Case
  • 20-VFQFN Exposed Pad, CSP
  • Number of Pins
  • 20
  • Operating Temperature
  • -40°C~85°C
  • Packaging
  • Tape & Reel (TR)
  • JESD-609 Code
  • e3
  • Pbfree Code
  • no
  • Part Status
  • Active
  • Moisture Sensitivity Level (MSL)
  • 3 (168 Hours)
  • Number of Terminations
  • 20
  • ECCN Code
  • EAR99
  • Type
  • Stereo Audio
  • Terminal Finish
  • Matte Tin (Sn)
  • Terminal Position
  • QUAD
  • Peak Reflow Temperature (Cel)
  • 260
  • Number of Functions
  • 1
  • Supply Voltage
  • 3.3V
  • Terminal Pitch
  • 0.5mm
  • Time@Peak Reflow Temperature-Max (s)
  • 30
  • Base Part Number
  • SSM2604
  • Pin Count
  • 20
  • Max Supply Voltage
  • 3.6V
  • Min Supply Voltage
  • 1.5V
  • Data Interface
  • Serial
  • Sampling Rate
  • 96 ksps
  • Voltage - Supply, Analog
  • 1.8V~3.6V
  • Voltage - Supply, Digital
  • 1.5V~3.6V
  • Signal to Noise Ratio (SNR)
  • 90 dB
  • Number of D/A Converters
  • 2
  • Resolution (Bits)
  • 24 b
  • Sigma Delta
  • No
  • Number of ADCs / DACs
  • 2 / 2
  • Filter
  • YES
  • S/N Ratio, ADCs / DACs (db) Typ
  • 90 / 100
  • Length
  • 4mm
  • Height Seated (Max)
  • 1mm
  • Width
  • 4mm
  • REACH SVHC
  • No SVHC
  • RoHS Status
  • RoHS Compliant
  • Lead Free
  • Contains Lead

Download datasheets and manufacturer documentation for ADI SSM2604CPZ-REEL7.

Datasheets:

ConflictMineralStatement:

SSM2604CPZ-REEL7 Overview


A 20-VFQFN Exposed Pad, CSP package is supplied for space savings. It is adopted to package in the manner of Tape & Reel (TR). This electronic component is of the type Stereo Audio, allowing it to provide high-efficiency performance in various applications. This device employs the mounting type Surface Mount. When the operating performance is set to -40°C~85°C, the system can operate normally. The unit is integrated with 2 / 2 ADCs / DACs. 1.8V~3.6V of supply voltage are applied to the analog circuit. A 1.5V~3.6V supply voltage is applied to the digital circuit. The transmission line is terminated with 20 terminations to prevent reflection of signals. This device consists of a row of 20-pins. It has a configuration of 20 pins. Its base part number SSM2604 can be used to find more related items. This device is mounted on a PCB which uses the Surface Mount technology. Supply voltage should never exceed 3.6V. At a minimum, the voltage should be kept at 1.5V. A voltage of 3.3V is required to operate the device. The conversion of digital signals into analog signals is done using D/A converters, and there are 2 D/A converters available.
