NXP SSL2103T/1,518

Manufacturer No:

SSL2103T/1,518

Manufacturer:

NXP

Package:

14-SOIC (0.154, 3.90mm Width)

Description:

PMIC GreenChip? Series SSL2103 100kHz 14-SOIC (0.154, 3.90mm Width)

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

SSL2103T/1,518 information

NXP SSL2103T/1,518 technical specifications, attributes, parameters and parts with similar specifications to NXP SSL2103T/1,518.

Type
Parameter

Mounting Type
Surface Mount

Package / Case
14-SOIC (0.154, 3.90mm Width)

Surface Mount
YES

Operating Temperature
-40°C~100°C TA

Packaging
Tape & Reel (TR)

Series
GreenChip?

Published
2010

Part Status
Discontinued

Moisture Sensitivity Level (MSL)
3 (168 Hours)

Number of Terminations
14

Type
AC DC Offline Switcher

Subcategory
Switching Regulator or Controllers

Terminal Position
DUAL

Terminal Form
GULL WING

Number of Functions
1

Frequency
100kHz

Base Part Number
SSL2103

Pin Count
14

Number of Outputs
1

Input Voltage-Nom
20V

Topology
Flyback, Step-Down (Buck)

Control Mode
VOLTAGE-MODE

Input Voltage (Max)
28V

Control Technique
PULSE WIDTH MODULATION

Internal Switch(s)
No

Dimming
Triac

Voltage - Supply (Max)
28V

Voltage - Supply (Min)
12V

Length
8.65mm

Width
3.9mm

RoHS Status
RoHS Compliant

Download datasheets and manufacturer documentation for NXP SSL2103T/1,518.

SSL2103T/1,518 Overview

The 14-SOIC (0.154, 3.90mm Width) package is used for saving board space. LED drivers with this design have 1 outputs.For mounting, it uses the Surface Mount method.It emerges as a AC DC Offline Switcher, which is efficient and reliable.The led light driver is capable of operating at the operating temperature of -40°C~100°C TA.100kHz is the frequency in which it operates.There are 14 terminations that are designed to operate with it.Undetermined failures may occur when the voltage supply is less than 12V.It is under the base part number SSL2103 that you can find this LED driver.There are 14 pins on it.28V is the maximum value of supply voltage it offers.In addition, its characteristics are classified into Switching Regulator or Controllers.LED drivers in the GreenChip? series are essential for a wide range of applications.Device operation requires 20V volts from the circuit.It is possible to ensure high stability by keeping the input voltage below 28V.

SSL2103T/1,518 Features

Available in the 14-SOIC (0.154, 3.90mm Width) package
Operating temperature of -40°C~100°C TA
Frequency of 100kHz

SSL2103T/1,518 Applications

There are a lot of NXP USA Inc.
SSL2103T/1,518 LED Driver ICs applications.

Street lighting
Stage and Studio lighting
Refrigeration lighting
Portable lighting
Gallery lighting
Museum lighting
High-end retail lighting
Medical surgery lighting
Replacement lamps
Panel lighting
