TI SN74LVC1G32YEPR

Manufacturer No:

SN74LVC1G32YEPR

Manufacturer:

Package:

5-XFBGA, DSBGA

Description:

3.3V V 4 ns ns Gates & Inverters Surface Mount Surface Mount 1.65V~5.5V V 10μA μA

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

SN74LVC1G32YEPR information

TI SN74LVC1G32YEPR technical specifications, attributes, parameters and parts with similar specifications to TI SN74LVC1G32YEPR.

Type
Parameter

Mount
Surface Mount

Mounting Type
Surface Mount

Package / Case
5-XFBGA, DSBGA

Operating Temperature
-40°C~85°C

Packaging
Tape & Reel (TR)

Series
74LVC

Part Status
Obsolete

Moisture Sensitivity Level (MSL)
1 (Unlimited)

Number of Terminations
5

Subcategory
Gates

Packing Method
TAPE AND REEL

Technology
CMOS

Voltage - Supply
1.65V~5.5V

Terminal Position
BOTTOM

Terminal Form
BALL

Peak Reflow Temperature (Cel)
NOT SPECIFIED

Number of Functions
1

Supply Voltage
1.8V

Terminal Pitch
0.5mm

Reach Compliance Code
not_compliant

Time@Peak Reflow Temperature-Max (s)
NOT SPECIFIED

Base Part Number
74LVC1G32

Pin Count
5

JESD-30 Code
R-XBGA-B5

Supply Voltage-Max (Vsup)
5.5V

Power Supplies
3.3V

Number of Circuits
1

Load Capacitance
50pF

Propagation Delay
4 ns

Quiescent Current
10μA

Family
LVC/LCX/Z

Logic Function
OR

Number of Inputs
2

Current - Output High, Low
32mA 32mA

Logic Type
OR Gate

Max Propagation Delay @ V, Max CL
4ns @ 5V, 50pF

Prop. Delay@Nom-Sup
4.5 ns

Schmitt Trigger
NO

Logic Level - Low
0.7V ~ 0.8V

Logic Level - High
1.7V ~ 2V

Height Seated (Max)
0.5mm

Width
0.9mm

RoHS Status
RoHS Compliant

Download datasheets and manufacturer documentation for TI SN74LVC1G32YEPR.

SN74LVC1G32YEPR Overview

The part is convenient to ship overseas because it is packed in a 5-XFBGA, DSBGA. The advanced packaging method Tape & Reel (TR) provides high reliability. A OR Gate logic principle governs its operation. Voltage 1.65V~5.5V is needed to ensure the part's full functionality. Operational temperature extended around -40°C~85°C. Mounted in Surface Mount. Output current is 32mA 32mA in the high and low states. 74LVC is the series it belongs to. The total number of terminations is 5. There are 1 functions that significantly improve the user experience. As part of LVC/LCX/Z, this chip is used. Try searching with 74LVC1G32 to find device variants. A total of 5 pins are injected into the body of the part. Logic devices with Surface Mount mounting are widely used in many applications. Inputs are limited to 2. Quiescent parts have 10μA current flowing through them. Gates is a typical logic device. The device consists of 1 circuits. There is 50pF load capacitance on the part. Vsup reaches its maximum value at 5.5V. The method TAPE AND REEL is packed into it. This part requires 3.3V power supplies, according to its datasheet.
